6mm Small Vibration Device – 12mm Type Model NFP-P0612-4408
$5.00
Experience seamless performance with the 6mm Small Vibration Device. Ideal for smartphones, this motor ensures effective and efficient vibration.
75 in stock
| Quantity | Price | Discount |
|---|---|---|
| 1 - 99 | $5.00 | 0% |
| 100 - 999 | $1.50 | 70% |
| 1000+ | $1.16 | 76.80% |
1.3V 6mm Small Vibration Motor 12.2mm Type Model NFP-P0612-4408
Product Overview
The NFP-P0612-4408 is a 6mm cylindrical ERM vibration motor. Therefore, it is suitable for compact products that need vibration alerts or simple haptic feedback.
In addition, ERM vibration motors are also called pager motors. As a result, they are widely used in mobile devices, small electronics, handheld tools, and wearable products.
Moreover, this model uses a 1.3V DC rated voltage and a low start voltage. Therefore, it can work well in small battery-powered designs.
Main Features
- Small 6mm body: The motor has a 6mm diameter. Therefore, it fits compact product structures.
- Low voltage drive: The rated voltage is 1.3V DC. As a result, it can support low-power device designs.
- Low start voltage: The start voltage is ≤ 0.8V DC. Therefore, the motor can start under low-voltage conditions.
- ERM vibration output: The eccentric rotating mass creates vibration during rotation. In addition, it provides simple tactile feedback.
- CW rotation: The motor runs clockwise. Therefore, users should check the rotation direction before product testing.
Technical Specifications
The table below shows the main motor data. Therefore, users can check current, speed, start voltage, size, rated voltage, and load data before sample testing.
| Motor Model: | NFP-P0612-4408 |
|---|---|
| Load Current: | ≤ 60mA |
| Load Speed: | 6,600rpm ± 500rpm |
| Start Voltage: | ≤ 0.8V DC |
| Stall Current: | ≤ 250mA |
| Rotation: | CW |
| Resistance at 100V: | >5MΩ |
| Motor Diameter: | Ø6.0mm ± 0.05mm |
| Motor Length: | 12.2mm ± 0.2mm |
| Total Length: | 17.7mm ± 0.3mm |
| End Play: | 0.05mm – 0.3mm |
| Rated Voltage: | 1.3V DC |
| Rated Load: | R – 3mm, L – 4.5mm |
Eccentric Rotating Mass Vibration Motor Outline Drawing
ERM Motor Structure
The outline drawing below shows the 6mm cylindrical vibration motor structure. Therefore, users can check motor length, total length, and load size before product design.
In addition, the eccentric mass creates vibration as the motor rotates. As a result, the motor can provide alert vibration or haptic feedback in compact devices.
Moreover, users should confirm PCB space, battery voltage, and mounting method before mass production. Therefore, early sample testing is important.
6mm Pager Motors Application
Typical Application Areas
Small ERM motors can support many compact products. For example, users can apply them to devices that need alerts, reminders, or tactile feedback.
In addition, the small cylindrical body helps engineers place the motor inside narrow product spaces. As a result, it works well for prototype projects and compact device design.
- Mobile devices: The motor can provide vibration alerts for calls, messages, and reminders.
- Wearable electronics: The small size helps fit compact wearable products.
- Medical devices: The motor can support small alert and feedback functions.
- Haptic feedback products: The ERM structure provides simple vibration feedback.
- DIY prototype projects: Users can test vibration feedback in small custom devices.
Product Design Notes
- Check voltage: Use 1.3V DC rated input. Therefore, the motor can run within its rated range.
- Check start voltage: Make sure the power source can meet the ≤ 0.8V DC start voltage requirement.
- Check current: Confirm that the circuit can support the load current and stall current.
- Check motor space: Confirm the 6mm diameter, 12.2mm motor length, and 17.7mm total length before assembly.
- Check mounting method: Fix the motor firmly. Otherwise, loose mounting may reduce vibration transfer.
