12mm Standard Gear Motor Model NFP-GM12-N10VA

1.5V, 3.0V, 6.0V NFP-GM12-N10VA DC Gearmotor Parameters

First, the NFP-GM12-N10VA series is a compact 12mm DC gearmotor family with 1.5V, 3.0V, and 6.0V motor options. Also, it offers multiple gear ratios for small drive systems.

In addition, these miniature gear motors provide a wide speed and torque range. Therefore, they are suitable for robotics, smart devices, precision tools, and small automation products.

Moreover, the N10 gear motor is smaller than many N20 gear motor options. As a result, it is useful when product space is limited.

Main Product Features

• First, compact 12mm gearbox: The small gearbox helps fit tight product spaces.
• In addition, voltage options: The series supports 1.5V DC, 3.0V DC, and 6.0V DC motors.
• Also, wide ratio range: Ratios from 10:1 to 1000:1 support many speed and torque needs.
• Next, small N10 motor size: The motor is smaller than the N20 type for compact designs.
• Moreover, custom support: Users can request gear ratio, voltage, shaft length, speed, and torque changes.
• Finally, mass production support: Custom terminal wires and JST connector options are available.

Single Motor Technical Data

First, the table below compares the base motor data before selecting a gearbox ratio. Also, it helps users check voltage, no-load speed, current, output, stall torque, and stall current.

Therefore, users can choose the base motor voltage before selecting the ratio. In addition, the 6.0V DC motor provides the highest listed no-load speed in this table.

NFP-GM12-N10VA Gear Motor Performance Data

Gear Motor NFP-GM12-N10VA-07280 Technical Data

First, the NFP-GM12-N10VA-07280 version uses a 3.0V DC motor. Also, it is suitable for compact products that need low voltage and precise motion.

In addition, lower ratios provide faster output speed. However, higher ratios provide lower speed and stronger instant torque.

As a result, the 3.0V version covers no-load speeds from 11rpm to 1100rpm. Moreover, the 1000:1 ratio provides the strongest instant torque in this table.

Gear Motor NFP-GM12-N10VA-12110 Technical Data

Next, the NFP-GM12-N10VA-12110 version uses a 1.5V DC motor. Therefore, it is useful for low-voltage battery products and miniature drive systems.

Also, this version provides several speed and torque choices. As a result, users can match the ratio to the required movement speed.

Therefore, the 1.5V version covers no-load speeds from 14rpm to 1400rpm. In addition, the 1000:1 ratio provides the strongest rated torque and instant torque in this table.

Gear Motor NFP-GM12-N10VA-06350 Technical Data

Furthermore, the NFP-GM12-N10VA-06350 version uses a 6.0V DC motor. Therefore, it is suitable for products that need higher motor speed in a compact N10 gearbox.

In addition, this version provides the highest no-load speed among the listed gearbox motor versions. As a result, it can support faster motion in small drive systems.

In conclusion, the 6.0V version covers no-load speeds from 19rpm to 1850rpm. Also, the 1000:1 ratio provides the strongest instant torque in this table.

Performance Selection Notes

• First, for higher speed: Choose lower ratios such as 10:1, 30:1, or 50:1.
• In addition, for balanced output: Choose 100:1, 150:1, 210:1, 250:1, 298:1, or 380:1.
• Also, for higher torque: Choose 1000:1.
• Next, for low-voltage products: Choose 1.5V or 3.0V based on the battery system.
• Moreover, for faster products: Choose the 6.0V version when higher speed is required.
• Finally, for custom needs: Contact us if different voltage, shaft length, speed, torque, or wiring is required.

NFP-GM12-N10VA Small Gearmotors Outline Drawing

Motor Outline and Mounting Reference

First, the outline drawing helps users check the N10 gear motor size, gearbox length, shaft position, and mounting space. Therefore, it is useful before sample testing and product design.

In addition, this small N10 gear motor is smaller than the N20 type. As a result, it can fit compact products that need a smaller drive unit.

Moreover, the 1.5V, 3V, and 6V DC small brushed DC gearmotors are available with gear ratios from 10:1 up to 1000:1. Therefore, users can find a suitable solution for many small drive systems.

Outline Drawing and Design Benefits

• First, compact N10 motor: The motor is smaller than many N20 gear motor options.
• In addition, wide ratio range: Ratios from 10:1 to 1000:1 support speed or torque needs.
• Also, multiple voltage options: Users can choose 1.5V, 3V, or 6V DC.
• Next, 9mm gearbox option: Many ratios use a short 9mm gearbox length.
• Moreover, 12.5mm gearbox option: The 1000:1 ratio uses a longer gearbox for higher torque.
• Finally, clear drawing: The outline helps users design brackets, holders, and housings.

N10 Mini Gear Motor In Mass Production

Mass Production and Custom Wiring

First, the following image shows the mass production of N10 Gear Motors. Also, these motors can connect to custom terminal wires with JST connector SUHR.

In addition, custom wiring helps the motor fit different PCB layouts and assembly methods. Therefore, users can request special wire length, connector type, and terminal direction.

Moreover, users can contact us through the form below and share customization requirements. For example, users can request gear ratio, voltage, shaft length, speed, torque, and other parameters.

Mass Production Benefits

• First, stable supply: Mass production helps support repeat orders.
• In addition, custom wires: Wire length and connector type can be adjusted.
• Also, JST connector support: The SUHR connector can support compact PCB assembly.
• Next, ratio options: Users can choose the required gearbox ratio.
• Moreover, voltage options: Users can select 1.5V, 3V, or 6V motor versions.
• Finally, project support: Custom shaft, speed, and torque requirements can be reviewed.

Applications and Selection Tips

Typical Applications

Finally, this NFP-GM12-N10VA DC gearmotor series is useful for compact products that need small size, low voltage, and flexible gear ratios. For example, it can work in robotics, smart devices, automation modules, toys, locks, and miniature instruments.

• First, robotics: The small motor can drive wheels, arms, grippers, and small moving parts.
• In addition, smart devices: The compact N10 gearbox helps save internal product space.
• Also, automation modules: The gearmotor can provide low-speed controlled movement.
• Next, toys and models: The low-voltage motor options support small battery-powered products.
• Moreover, locks and latches: Higher ratios can support stronger movement at lower speed.
• Finally, miniature instruments: The small size helps fit precision equipment.

How to Choose the Right Version

First, choose the base motor voltage based on the power supply. Also, choose the ratio based on output speed, rated torque, instant torque, and gearbox length.

In addition, lower ratios provide faster output speed. Therefore, they are better for quick movement and lighter loads.

Moreover, higher ratios provide slower output and stronger instant torque. As a result, they are better for compact force-driven tasks.

Final Selection Notes

• First, check voltage: Choose 1.5V, 3V, or 6V based on the power supply.
• In addition, check ratio: Choose 10:1 to 1000:1 based on speed and torque needs.
• Also, check gearbox length: Use 9mm gearbox options when shorter length is needed.
• Next, check torque: Use 1000:1 when stronger instant torque is required.
• Moreover, check customization: Confirm shaft, wires, connector, and voltage before production.
• Finally, test real load: Confirm speed, current, torque, noise, temperature, and service life before mass production.

In short, the NFP-GM12-N10VA DC gearmotor series is a compact small gear motor solution for products that need 1.5V, 3V, or 6V DC power, N10 motor size, flexible ratios, custom wiring, and low-speed drive output.
