4mm Small Vibration Device – 11mm Type Model NFP-P0411-272

$3.00

(3 customer reviews)

Order Low Volume Pricing(USD)

QTY BREAK UNIT PRICE
1+ $3.00
100+ $1.10
1,000+ $0.95

Contact us for a quotation for production quantities, customizations and integration.

4mm Tiny Vibration Motor – 11mm Wire Length 1.5V DC Model NFP-P0411-272 Parameters


Motor Model: NFP-P0411-272
Rated Voltage: 1.5V DC
Diameter: 4.0mm ± 0.05mm
Total Length: 14.6mm ± 0.3mm
Motor Length: 10.8mm ± 0.2mm
End Play: 0.05mm – 0.3mm
Resistance 100V: >5MΩ
Rotation: CW
Stall Current: <100mA
Start Voltage: <0.9V
Load Speed: 13,000rpm ± 15%
Load Current: <60mA
Ecc. Weight Radius: 2.0mm
Ecc. Weight Length: 3.0mm
Amplitude: 1.15G



1.5 Volt Eccentric Rotating Mass Vibrating Motor 13,000RPM Outline Drawing


types-of-vibration-motors

Keywords:
mini vibration motor, 4mm motor, smallest vibration motor, tiny vibration motors

Payment:
1.Payment methods : Paypal, T/T

Shipping:
1.Delivery: DHL/FedEx 3-5 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.

FAQ
Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It’s better to offer application prototype drawings to us if possible.

Q: What’s your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.

Q: What’s the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.

Still can’t find ideal motors?


The electrical parameters of the motor can be adjusted. For example, the two main factors determining the vibration force: the size of the pager motor eccentric mass and the speed requirement. , voltage, current can be adjusted according to customer needs. Some encapsulated vibration motors adding terminals connectors, which are our customized products according to different customers. You can also contact us in the bottom contact form to ask for your needs.

If you want a custom lead wire connection of the water resistant vibration motors. Such as alternate lead wire length & strip lengths, with a connector (e.g. Molex, JST). You can contact us from the footer form, tell us your need. Any problems will be taken seriously and will be answered professionally, so pls do not hesitate to contact us by the footer form.

Free Shipping Site-wide When You Spend More Than $150

Using The Following Coupon When You’re Going To The Checkout

3 reviews for 4mm Small Vibration Device - 11mm Type Model NFP-P0411-272

  1. Nitzan Dolev

    They were good micro erm motors and vibrated well. My only complaint is that there wasn’t enough bare copper at the end of the wires, of cause we stripped further manually finally. And in some applications, if the pager motor did not be fixed on something, be sure drop a glob of hot glue on the back connections to prevent wires from disconnecting. I scrapped two motors to come to this conclusion…

  2. Valentina Lelli

    I thought this would have high speed and in fact, it is. Small vibration motor is fine and works as expected, isn’t noisy. I guess I judged its power is right.

  3. Lior Goldenberg

    Very tiny vibrating motor, lightweight but high-precision, it can keep my application running, and really low noise.
