10mm Coin Vibration Motor – 2mm Type Model NFP-C1027

$3.00

(6 customer reviews)

Button Vibration Motors Small Volume Price (USD)

QTY BREAK UNIT PRICE
1+ $3.00
100+ $0.99
1,000+ $0.85

Contact us for a quotation for production quantities, customizations and integration.

DATA SHEET

10mm Flat Coin Vibration Motor 2.7mm Type Model NFP-C1027 Performance


Coin vibration motors, also known as shaftless or pancake vibrator motors. 1027 coin flat vibration motor DC 3V 11000rpm 10mmx2.7mm for mobile phone, It is a high speed coin vibration motor in size 10*2.7mm. The rated speed is 11000 rpm at 3v.

Motor Model: NFP-C1027L wire length type
Motor Diameter: 10.0mm
Motor Thickness: 2.7mm
Rated Voltage: 3.0V DC
Rated Speed: 14,000rpm
Rated Current: 90mA max
Typical Rated Operating Current: 61mA
Nominal Amplitude Vibe Force: 1.20G



NFP-C1027 Pancake Vibration Motor Outline Drawing


It’s wildly used in mobile phone,personal care, dental equipment, Dental equipment, Beauty product, Mobile Phone, Cell Phone, Pager, Personal care,Health product equipment ,Massager, Massage Rod, Eye Massager, Body Massager, Vibrator.etc.

1027-coin-vibration-motor

Pack Of Coin/Pancake/Button Vibration Motors

Pack Of Coin Vibration Motors

Keywords:
miniature vibration motors, micro vibration motor, coin vibration motor, vibration motor kit, vibration motor arduino, 426-FIT0774, FIT0774

Payment:
1.Payment methods : Paypal, T/T

Shipping:
1.Delivery: DHL/FedEx 3-5 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you havenโ€™t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.

FAQ
Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It’s better to offer application prototype drawings to us if possible.

Q: What’s your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.

Q: What’s the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.
