10mm Coreless DC Motor – 20mm Type Model NFP-D1020T
$5.00
Experience unmatched efficiency with the 10mm dc motor wire type, delivering maximum output power for your projects. Start enhancing today!
Notice: this motor model need to make new ones that would take extra 2-3 weeks.
| Quantity | Price | Discount |
|---|---|---|
| 20 - 99 | $5.00 | 0% |
| 100 - 999 | $3.15 | 37% |
| 1000+ | $2.40 | 52% |
10mm Small DC Motors Data Sheet
First, this 10mm small DC motor uses a metal brush and a coreless rotor. Because it has a slim body and high speed, it is useful for small drive systems.
In addition, the motor is a good choice for compact products that need fast output. Also, the 3.7V and 7.4V options help users match different power systems.
Main Product Features
- First, small size: The 10mm body fits tight spaces.
- Also, high speed: The motor can reach up to 51,500rpm.
- In addition, light weight: Each motor weighs about 7.5g.
- Next, strong torque: The 7.4V version provides up to 209.55g.cm stall torque.
- Finally, custom work: Wires, plugs, and ERM weights can be added for bulk orders.
10mm Small DC Motor Performance Data
Next, the table below helps users compare voltage, speed, current, torque, power, efficiency, and weight. Therefore, it is easier to choose the right NFP-D1020T model for a compact product.
| Model | NFP-D1020T-1437-C-1-3.7 | NFP-D1020T-1437-C-2-7.4 |
|---|---|---|
| Voltage | 3.7V | 7.4V |
| Terminal resistance | 0.2Ω | 0.5Ω |
| No-load speed | 45,000rpm | 51,500rpm |
| No-load current | 240mA | 180mA |
| Stall torque | 120.36g.cm | 209.55g.cm |
| Stall current | 16,370mA | 15,740mA |
| Max output power | 13.896W | 27.687W |
| Max efficiency | 73% | 78% |
| Torque constant | 7.5g.cm/A | 13.5g.cm/A |
| Rotor inertia | <0.3g.cm² | <0.3g.cm² |
| Weight | 7.5g | 7.5g |
Also, the 7.4V version gives higher speed, stronger torque, higher output power, and better efficiency. However, the 3.7V version is useful for lower-voltage compact systems.
As a result, users can choose the 7.4V model for more power, or choose the 3.7V model for smaller low-voltage devices.
10mm DC Motors Outline Drawing
Next, the outline drawing shows the motor size and shaft shape. Therefore, it can help users check the fit before the final product design.
Also, custom work is available for bulk orders. For example, we can add a plug, change the wire length, or add an eccentric rotating mass for vibration use.
Outline Drawing and Custom Options
- First, dual-shaft structure: The drawing helps users check the shaft layout.
- In addition, compact body: The 10mm motor can fit small product spaces.
- Also, plug option: A plug can be added for bulk orders.
- Next, wire option: Wire length can be changed based on project needs.
- Finally, ERM option: An eccentric rotating mass can be added for vibration use.
Terminal Wire Note
In addition, if you need terminal wires, please send us an email with your wire needs. Because wire work takes extra labor, extra fees may apply.
Note: The MOQ for terminal wire work is 100pcs. However, by default, the motor is sent without terminals.
As a result, custom wire work should be confirmed before bulk production. Finally, custom wire work can be arranged when the order meets the required quantity.
Custom Wire Process
- First, tell us the wire length.
- Next, tell us the plug or terminal type.
- Also, confirm the order quantity.
- Finally, we will check the cost and lead time.
Typical Applications
- Small vibration devices
- Compact drive systems
- Portable electronic products
- Electric toys
- Small robots
- Custom high-speed motor projects
Finally, the NFP-D1020T 10mm small DC motor is a good fit for compact products that need high speed, strong torque, light weight, and custom wire options.
Keywords: 10mm dc motor, mini dc motor, tiny dc motor, high torque dc motor, dc motor small
1.Payment methods : Paypal, T/T
Shipping:
1.Delivery: DHL/FedEx 3-5 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.
FAQ
Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It’s better to offer application prototype drawings to us if possible.
Q: What’s your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.
Q: What’s the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.
