10mm Small Vibration Motor – 15mm Type Model NFP-M20VAZ-07180
$5.00
Enhance your devices with our M20 vibration motor featuring an inline shaft orientation. Explore our extensive collection and get yours now!
| Quantity | Price | Discount |
|---|---|---|
| 20 - 99 | $4.50 | 10% |
| 100 - 499 | $2.79 | 44.20% |
| 500+ | $1.19 | 76.20% |
10mm Micro Vibration Motor – 15mm Type Data Sheet
3V Vibration Motors, 12mm Diameter, 15mm Motor Length. Slight Delivery Time & Express Shipment, Excellent Service, Huge Collection in stock, Look for Business Partner.
| Motor model | NFP-M20VAZ-07180 |
|---|---|
| Body diameter | 10.0mm |
| Body length | 15.0mm |
| Ecc. weight radius | 4.5mm |
| Ecc. weight length | 4.8mm |
| Shaft orientation | Inline |
| Rated operating voltage | 3.7V DC |
| Rated speed | 8,000RPM |
| Load current | ≤100mA |
| Typical amplitude | 7.5G |
3 V DC Small Vibration Motor Outline Drawing
Available in Eccentric Mass sizes:
R – 6.0mm x L – 4.8mm
R – 5.5mm x L – 4.8mm
R – 5.0mm x L – 4.8mm
R – 4.5mm x L – 4.8mm
R – 5.8mm x L – 3.6mm
R – 5.5mm x L – 3.6mm
Keywords:
micro vibration motor, 3v vibration motor, M20 vibrating motor
Payment:
1.Payment methods : Paypal, T/T
Shipping:
1.Delivery: DHL/FedEx 3-5 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.
FAQ
Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It’s better to offer application prototype drawings to us if possible.
Q: What’s your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.
Q: What’s the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.
1.Payment methods : Paypal, T/T
Shipping:
1.Delivery: DHL/FedEx 3-5 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.
FAQ
Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It’s better to offer application prototype drawings to us if possible.
Q: What’s your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.
Q: What’s the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.
Maya Saanvi –
This motor is energy efficient and works well with my low voltage battery pack. It is reliable and efficient 👍.
Natalia Miller –
The motor is compact but powerful enough for my needs. I used it in a custom alarm system and it worked exactly as I expected. Excellent value for money!
Brean Lara –
I bought this motor to keep parts moving, and it does the job really well. Sometimes the parts get stuck, and a little shake from the motor does the trick. Works exactly as I hoped.🥸
Eugene Tsykalov –
I used this vibrating motor to build a simple vibrating cleaner, worked great, can add a voltage regulator to adjust amount of force on vibrator.
Chris Yoder –
The micro vibration motors were easy to install and work great, I bought two of these about one months ago. Small vibration motor works perfectly for the electric generator we needed to power our experiments.
Ethan Wood –
Excellent small 3v vibration dc motor, works smoothly and quietly, the eccenter and the shell were strong, all samples performed well in my new application.
Muhammad Hamza –
This small vibration motor is factory quality, it’s a standard M20 erm vibration motor, end play is acceptable for my massager prototype.👍
