12mm Metal Gear Motor Model NFP-GM12-MGB12P
$15.00
Experience the power of the N20 electric screwdriver gear motor! Perfect for mini electric screwdrivers, it simplifies your fastening needs. ⚡
N20 Hex Socket Electric Screwdriver Gear Motor Technical Sheet
The N20 hex socket electric screwdriver gear motor is a compact, high-torque micro DC gear motor specifically designed for mini electric screwdrivers and precision fastening tools. Featuring a standard hex socket output shaft, it enables direct bit connection without additional couplings, improving transmission efficiency and assembly reliability.
| Motor Model | NFP-GM12-MGB12P |
|---|---|
| Rated Voltage | 3V DC / 3.7V DC |
| No Load Speed | 120rpm / 150rpm |
| No Load Current | ≤130mA / ≤150mA |
| Ratio | 139:1 |
| Normal Torque | 1,000gf.cm |
| Breakdown Torque | 3,000gf.cm |
| Efficiency | 65% |
N20 DC Gear Motor For Cordless Screwdriver Outline Drawing
Built with a metal gear reduction gearbox, this N20 gear motor delivers stable low-speed rotation and strong torque output, making it ideal for controlled screw tightening and loosening. The optimized gear train ensures smooth operation, reduced backlash, and consistent torque performance, even under repeated start-stop conditions.
- The input is PMDC motor, which can adjust the speed and torque in real time.
- The gearbox adopts NGW planetary transmission, enabling high reduction ratio output in a compact size.
- Small size, high efficiency, long life and low noise.
- Application: household electric screwdriver.
Keywords:
gear reduction motor, variable speed electric motor, low rpm electric motor, mini dc gear motor, high torque gear motor
1.Payment methods : Paypal, T/T
Shipping:
1.Delivery: DHL/FedEx 3-5 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.
FAQ
Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It’s better to offer application prototype drawings to us if possible.
Q: What’s your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.
Q: What’s the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.
