16mm 3.7V DC Sonic Motor Low Nosie Model NFP-161242-020-02 Used As Electric Toothbrush Motor


(2 customer reviews)

Order Low Volume Pricing (USD)

1+ $5.00
100+ $2.35
1,000+ $2.20

Contact us for a quotation for production quantities, customizations and integration.

16mm Electric Sonic Toothbrush Motor Parameters

Motor model: NFP-161242-020-02
Voltage: 3.7V DC
Frequency: 360Hz
Duty cycle: 80%
Oscillation frequency: 43,200 times/min
No-load current: 74mA
End resistance: 3.92Ω
Length of shaft: 36.3mm ± 0.3mm
Wire length 35 ± 5mm


3.7V High Frequency Sound Wave Motor Outline Drawing


Typical Application:
electric toothbrush

sonic vibration motor, acoustic vibration motor, 3.7v high frequency toothbrush motor

1.Payment methods : Paypal, T/T

1.Delivery: DHL/FedEx 3-5 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.

Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It’s better to offer application prototype drawings to us if possible.

Q: What’s your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.

Q: What’s the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.

Still can’t find ideal motors?

The electrical parameters of the motor can be adjusted. For example, the two main factors determining the vibration force: the size of the pager motor eccentric mass and the speed requirement. , voltage, current can be adjusted according to customer needs. Some encapsulated vibration motors adding terminals connectors, which are our customized products according to different customers. You can also contact us in the bottom contact form to ask for your needs.

If you want a custom lead wire connection of the water resistant vibration motors. Such as alternate lead wire length & strip lengths, with a connector (e.g. Molex, JST). You can contact us from the footer form, tell us your need. Any problems will be taken seriously and will be answered professionally, so pls do not hesitate to contact us by the footer form.

Free Shipping Site-wide When You Spend More Than $150

Using The Following Coupon When You’re Going To The Checkout

2 reviews for 16mm 3.7V DC Sonic Motor Low Nosie Model NFP-161242-020-02 Used As Electric Toothbrush Motor

  1. Carlos

    Sonic vibration motor worked as expected had no problems, I used it to make electric toothbrush, which need a very high oscillation frequency and this motor is perfectly suitable. High quality electro-mechanical device.

  2. Ronen Paz

    Wonderful small sonic vibration 3.7v dc motor. It performed very well in our test of the new electric toothbrush, worked powerfully and really low noise.
