20mm Vibration Motor – 25mm Type Model NFP-130SHZ-B
5.00$
(8 votes, average: 4.75 out of 5)
Loading...| QTY BREAK | UNIT PRICE |
|---|---|
| 1+ | $5.00 |
| 10+ | $3.00 |
| 50+ | $2.50 |
| 100+ | $1.50 |
| 500+ | $1.35 |
| 1,000+ | $0.95 |
Contact us for a quotation for production quantities, customizations and integration.
3V Small Vibration Motor NFP-130SH-Z Datasheet
| Motor model No. | NFP-130SH-17105 |
| Voltage: | 3V DC |
| No-load speed: | 6,800rpm |
| No-load current: | 95mA |
| At Maximum Efficiency speed: | 5500rpm |
| At Maximum Efficiency current: | 380mA |
| Output: | 0.62W |
| Stall torque: | 51g.cm |
| Stall current: | 1.8A |
3.7V ERM Vibration Motor NFP-130SHZ-B Data Sheets
This NFP-130SH-38-3.7V small vibration motor is a popular type. You can use it for many applications, such as bed vibration motor, health products, massager and beauty equipment...
| Small vibration motor model: | NFP-130SH-38-3.7V |
| Rotation direction: | CCW |
| Voltage range for use: | DC 3.0-4.0V |
| No-load current: | ≤140mA |
| No-load speed: | 6,700±10% rpm |
| Rated Load: | R7mm*Φ2mm*8mm |
| Rated current: | ≤270mA |
| Rated speed: | 5,800±10% rpm |
| Starting voltage: | ≤1.2VDC |
| Insulation resistance: | ≥ 1MΩ |
| Starting Current: | ≤1.58A |
6V Eccentric Rotating Mass Vibration Motor NFP-130SHZ-B Performance
| Motor Model: | NFP-130SHZ-B |
| Voltage Range: | 4.5V DC - 7V DC |
| Nominal Voltage: | 6V DC |
| Eccentric Mass: | R9.0mm*6.0mm |
| Current: | 0.88A |
| Rate Speed: | 10,000 rpm |
| Stall Current: | 3.0A |
| Output Power: | 5.48W |
| Start Voltage: | 0.6V DC |
12V Micro Vibration Motor NFP-130SH-Z Data Sheet
| Motor model No. | NFP-130SH-07520 |
| Voltage: | 12V DC |
| No-load speed: | 5900rpm |
| No-load current: | 30mA |
| At Maximum Efficiency speed: | 5500rpm |
| At Maximum Efficiency current: | 50mA |
| Output: | 0.38W |
| Stall torque: | 35g.cm |
| Stall current: | 0.24A |
Small Vibration Motor Outline Drawing
Factory product quality, ODM or OEM support. It's a classic vibrating motor used for handle devices for vibration alerting.
Keywords:
large vibration motor, strongest vibrator, bed vibration motor, vibrating motors, powerful vibration, powerful vibration motor, strong vibration motor, vibrator motors, powerful small motor, vibro motors
Applications:
This motor has a wide range of applications, such as massage equipment, adult products, small mixers, medical devices and other applications. The following is the small vibration motor's typical application example that is shared by our recent customers. It is applied to the desktop powder dispenser and can efficiently dispense the calibrated volumetric dose through vibration. To learn more, you can watch the video below.
1.Payment methods : Paypal, T/T
Shipping:
1.Delivery: DHL door to door 3-4 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.
FAQ
Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It’s better to offer application prototype drawings to us if possible.
Q: What’s your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.
Q: What’s the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.
Still can’t find ideal motors?
The electrical parameters of the motor can be adjusted. For example, the two main factors determining the vibration force: the size of the pager motor eccentric mass and the speed requirement. , voltage, current can be adjusted according to customer needs. Some encapsulated vibration motors adding terminals connectors, which are our customized products according to different customers. You can also contact us in the bottom contact form to ask for your needs.
If you want a custom lead wire connection of the water resistant vibration motors. Such as alternate lead wire length & strip lengths, with a connector (e.g. Molex, JST). You can contact us from the footer form, tell us your need. Any problems will be taken seriously and will be answered professionally, so pls do not hesitate to contact us by the footer form.
