24mm Small Vibration Motor – 30mm Type Model NFP-F280V
$5.00
12V DC Vibration Motor Small Volume Price (USD)
| QTY BREAK | UNIT PRICE |
|---|---|
| 1+ | $5.00 |
| 10+ | $4.00 |
| 50+ | $3.59 |
| 100+ | $2.99 |
| 500+ | $1.49 |
Contact us for a quotation for production quantities, customizations and integration.
Out of stock
12V DC Vibration Motor Model NFP-F280V Parameters
Heavy duty vibration motor that operates at 12 VDC, currently use this motor to power a directional feeder that throws fish food. The feeder design requires significant vibration to force the fish food from the hopper down to the spin plate. Features an offset brass weight mounted on shaft ( 5/8” diameter ) .069: ½ moon brass flywheel.
| Motor model: | NFP-F280V |
|---|---|
| Voltage: | 12V DC |
| Diameter: | 24mm |
| Flat thickness: | 18mm |
| Body length: | 30.6mm |
| No load speed: | 3,000 RPM |
| No load current: | 270mA |
| Ecc. weight radius: | 8.5mm |
| Ecc. weight length: | 7mm |
12 Volt Vibrating Motor Outline Drawing
To check more large vibration motor information by the following link:
https://www.nfpmotor.com/products-micro-dc-motors-strong-vibration-motor-NFP-F280.html
Keywords:
small vibration motor, flat vibrator, types of vibration, ab vibrator, vibration device, 12 volt vibrating motor, small vibration motor
Payment:
1.Payment methods : Paypal, T/T
Shipping:
1.Delivery: DHL/FedEx 3-5 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.
FAQ
Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It’s better to offer application prototype drawings to us if possible.
Q: What’s your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.
Q: What’s the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.
Still can’t find ideal motors?
The electrical parameters of the motor can be adjusted. For example, the two main factors determining the vibration force: the size of the pager motor eccentric mass and the speed requirement. , voltage, current can be adjusted according to customer needs. Some encapsulated vibration motors adding terminals connectors, which are our customized products according to different customers. You can also contact us in the bottom contact form to ask for your needs.
If you want a custom lead wire connection of the water resistant vibration motors. Such as alternate lead wire length & strip lengths, with a connector (e.g. Molex, JST). You can contact us from the footer form, tell us your need. Any problems will be taken seriously and will be answered professionally, so pls do not hesitate to contact us by the footer form.
