3mm Small Vibration Motor – 8mm Type Model NFP-3C-03208B
$5.00
Smallest Vibration Motors Small Volume Price (USD)
| QTY BREAK | UNIT PRICE |
|---|---|
| 1+ | $5.00 |
| 100+ | $0.99 |
| 1,000+ | $0.85 |
Contact us for a quotation for production quantities, customizations and integration.
3mm Smallest Pager Motor Performance
These little motors have eccentric weights that make them vibrate when they spin. Like our pager motors, but bigger and stronger. What to do with them? We use motors just like this (but with longer leads) for the engraving attachment for the Eggbot kit. They’re also the perfect thing for making vibrobots, BEAM bots, and other little robots! They have wire leads attached that are color coded and have 2 mm pre-stripped and tinned ends.
| Motor Model: | NFP-3C-03208B |
|---|---|
| Rated Voltage: | 3.0V DC |
| Operating Voltage: | 2.5V – 3.6V |
| Rated Speed: | 16,000±3,000RPM |
| Rated current: | 90mA |
| Stall current: | 120mA |
| Start voltage: | 2.4V DC |
| Lifetime: | 0.5s on(C.W), 0.5s off, 100,000 cycles |
| Amplitude: | 0.85G |
Cylindrical Vibration Motor ERM Type Outline Drawing
3mm diameter small vibration motor can be integrated into a device, operators can rely on the sense of touch, no longer requiring line of sight or high volume. Eccentric Rotating Mass vibration motors, also commonly known as ERMs or pager motors, make up our main product lines.
They shot to popularity with use in pagers and have grown alongside the mobile / cell phone industry, where they are still extremely popular in pager motors. Now there are a wide range of applications that use these tiny vibration motors to offer vibration alert notifications and haptic feedback.
Keywords:
3mm dc motor, 3mm electric motor, micro dc motor
Payment:
1.Payment methods : Paypal, T/T
Shipping:
1.Delivery: DHL/FedEx 3-5 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.
FAQ
Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It’s better to offer application prototype drawings to us if possible.
Q: What’s your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.
Q: What’s the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.
Still can’t find ideal motors?
The electrical parameters of the motor can be adjusted. For example, the two main factors determining the vibration force: the size of the pager motor eccentric mass and the speed requirement. , voltage, current can be adjusted according to customer needs. Some encapsulated vibration motors adding terminals connectors, which are our customized products according to different customers. You can also contact us in the bottom contact form to ask for your needs.
If you want a custom lead wire connection of the water resistant vibration motors. Such as alternate lead wire length & strip lengths, with a connector (e.g. Molex, JST). You can contact us from the footer form, tell us your need. Any problems will be taken seriously and will be answered professionally, so pls do not hesitate to contact us by the footer form.
