10mm Small Vibration Motor – 15mm Type Model NFP-FF-M20SA-07170


(6 customer reviews)

Order Low Volume M20 Vibrating Motor Pricing (USD)

1+ $5.00
10+ $2.00
100+ $1.80
500+ $1.40
1,000+ $0.95

Contact us for a quotation for production quantities, customizations and integration.


15G Amplitude 3.7V Low Frequency Vibration Motor Used For Massager

This small vibration motor has a round flat body, Φ10mm diameter, a flat body dimension of 8mm, motor body length is 15mm. The body structure is relatively small and very suitable. The front swing head can be equipped with tungsten alloy pendulum, tinplate pendulum and copper pendulum.

Motor Model: NFP-FF-M20SA-07170
Motor Diameter: 10.0mm
Motor Length: 15.0mm
Rated Voltage: 3.7V DC
Voltage Range: 2.0V – 4.5V
Rated Load: Eccentric 7.0mm * 5.0mm
Load Speed: 9,500 ± 2,000rpm
Load Current: 180mA max
Amplitude: 15G


Small Vibration Motor Model NFP-FF-M20SA-07170 Outline Drawing


Used in beauty equipment, massage goggles, massage equipment, sex products, adult products, sex toys and other products.

3.7v vibration motor, what is a vibration motor, how vibration motor works, m20 vibration motor

1.Payment methods : Paypal, T/T

1.Delivery: DHL/FedEx 3-5 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.

Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It’s better to offer application prototype drawings to us if possible.

Q: What’s your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.

Q: What’s the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.

Free Shipping Site-wide When You Spend More Than $150

Click The Following Button To Copy the Coupon Code When You’re Going To The Checkout

Still can’t find ideal motors?

Get A Quote Within 8 Hours Contact Now! Any question about Micro DC Motor, Spec, Data-Sheet, Quote…

If you want a custom lead wire connection of the water resistant vibration motors. Such as alternate lead wire length & strip lengths, with a connector (e.g. Molex, JST). You can contact us from the footer form, tell us your need. Any problems will be taken seriously and will be answered professionally, so pls do not hesitate to contact us by the footer form.

6 reviews for 10mm Small Vibration Motor - 15mm Type Model NFP-FF-M20SA-07170

  1. Paul Atcheson

    These vibrating motors came with leads customized soldered on that worked fine for me, and even if they had come off, the motors themselves appeared to be of good quality, it wouldn’t have taken much to solder them back on. All my motors showed up perfectly packaged and worked as intended.

  2. Lionel MARKT

    The small M20 vibration motor is a powerful erm motor that is perfect for my application. It is strong and durable. Run really quietly and has a high vibration level.

  3. Chris LaCombe

    Powerful tiny 3.7 v vibration motor, with low starting voltage, it is friendly for our low energy massage equipment. There is no hardly noise when it working.😁

  4. Gerald Heinrichs

    Small M20 erm vibration motor’s vibration force is powerful for my massager, big brass weight is perfect, I use 3.7V lithium polymer battery to drive.

  5. Debra Haak

    This M20 vibration motor with big copper eccentric rotating mass wonderful suit for our company’s massager machine and runs well within the specified load range.

  6. Plamen Balkandjiev

    10pcs M20VAZ vibration motor arrived super fast, I ordered some products for fatigue test, and then mass production after a week, fast delivery, on time, to spec.
