12mm Brushless Vibration Motor – 15mm Type Model NFP-1215-912-101
$27.50
Discover the reliability of our 12mm brushless vibration motor long lifetime for your applications. Enhance performance with our high-quality product! 🔧
| Quantity | Price | Discount |
|---|---|---|
| 1 - 9 | $27.50 | 0% |
| 10 - 49 | $26.50 | 3.64% |
| 50 - 99 | $24.00 | 12.73% |
| 100 - 499 | $22.50 | 18.18% |
| 500 - 999 | $13.40 | 51.27% |
| 1000+ | $12.90 | 53.09% |
30G Amplitude 1215 BLDC Vibration Motor Data Sheet
Product Overview
The NFP-1215-912-101 is a 12mm diameter brushless vibration motor with high vibration amplitude. Therefore, it is suitable for applications that require strong vibration force, compact size, and long service life.
Unlike brushed vibration motors, this BLDC vibration motor removes the brush and commutator contact structure. As a result, it can greatly improve lifetime performance when compared with brushed ERM vibration motors.
In addition, this 5V ERM brushless vibration motor requires a suitable driver. For example, the M10-400 driver or a compatible BLDC driver can be used for motor testing.
Recommended Driver
The driver we normally recommend for this BLDC motor is the DRV11873 from Texas Instruments. However, we are not a driver manufacturer, so the driver information is provided only as a reference.
- Recommended driver: DRV11873 from Texas Instruments
- Product page: https://www.ti.com/product/DRV11873
- DRV11873 datasheet: DATASHEET
Main Features
- Sensorless design: The motor uses an efficient sensorless configuration. Therefore, it can operate with fewer parts and lower maintenance needs.
- Wide application range: It is suitable for medical equipment, industrial machinery, RC models, power tools, and small appliances.
- Tungsten alloy eccentric rotor: The motor uses a durable tungsten alloy eccentric wheel. As a result, it can provide high vibration amplitude and stable performance.
- Long lifespan: It is rated for 1000 to 3000 hours of continuous operation under normal conditions.
- Wide operating environment: It can work within a temperature range of -15°C to +50°C and humidity levels from 15% to 90% RH.
Motor Specifications
The following table shows the main electrical and mechanical parameters. Therefore, engineers can check the voltage, current, speed, resistance, and vibration amplitude before testing.
| Motor Model: | NFP-1215-912-101 |
|---|---|
| Motor Diameter: | 12mm |
| Motor Length: | 15mm |
| Rated Voltage: | 5.0V DC |
| No. Of Phase: | 3 phase |
| KV Value: | 3,600rpm |
| Rated Load: | Tungsten steel vibrator R5.7*5mm |
| Voltage Range: | 4.9V – 6.5V DC |
| Temperature Range: | -10℃ – 50℃ |
| Rated Speed: | 12,000rpm ± 15% |
| Rated Current: | 380mA |
| Stall Current: | 850mA Max |
| Start Voltage: | 4.9V Max |
| Terminal Resistance: | 6.5Ω ± 15% |
| Vibration Amplitude: | 30G |
912-101 12mm Brushless Vibration Motor 15mm Type Outline Drawing
Mechanical Structure
The 912-101 brushless vibration motor removes the main failure source found in brushed motors. Therefore, there are no precious metal brushes rubbing against the commutator.
In addition, this brushless vibrating motor generates vibration through an eccentric rotating mass. As a result, it can provide strong vibration output while improving long-term reliability.
BLDC Motor Without Eccentric Rotating Mass Working Performance Curve
Performance Curve Reference
The 30G amplitude 12mm brushless vibration motor is designed for demanding applications. Therefore, it can provide reliable vibration performance for medical devices, industrial equipment, and remote-controlled models.
Moreover, the tungsten alloy eccentric rotor improves durability and vibration intensity. As a result, this motor is a practical choice for projects that need strong and consistent vibration force.
12mm Brushless Vibration Motor Mass Production
Production and Application Advantages
This motor has a low start voltage, compact size, and high vibration amplitude. Therefore, it is suitable for heavy-duty applications that require long service life.
In addition, it provides a larger vibration force than many similar-size ERM motors. As a result, it can support stronger feedback in compact devices.
How To Test The BLDC Vibration Motors?
Testing Notes
This small vibration motor is not a common brush type motor. Instead, it is a brushless vibration motor with a lifetime of more than one thousand hours.
Therefore, please use a suitable BLDC driver during testing. In addition, please confirm the rated voltage, wiring method, and driver settings before powering the motor.
Energy Efficiency and Customization
Energy Efficiency and Customization: The 12mm brushless vibration motor provides high energy efficiency. As a result, it can run for longer periods while maintaining stable performance.
Moreover, customization is available for specific vibration amplitude requirements. Therefore, it can be used in a wide range of product designs.
Typical Applications
This motor is suitable for applications that require strong vibration, stable operation, and long lifetime. For example, it can be used in precision products and compact equipment.
- Medical instruments: It supports applications where precision and reliability are important.
- Industrial equipment: It helps reduce downtime because of its durable brushless structure.
- RC models: It provides smooth and consistent vibration feedback.
- Power tools: It can support strong vibration output in compact assemblies.
- Small appliances: It offers efficient and reliable vibration performance for daily-use products.
Keywords:
brushless vibration motor, dc brushless vibration motor, brushless motor anti vibration, brushless vibracion, motor brushless vibration, 912-101
1.Payment methods : Paypal, T/T
Shipping:
1.Delivery: DHL/FedEx 3-5 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.
FAQ
Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It’s better to offer application prototype drawings to us if possible.
Q: What’s your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.
Q: What’s the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.
