37mm DC Motor With Photoelectric Encoder − 55mm Type Model NFP-GM37-520-PEN

Reduction Gearbox DC Carbon Brush Motor Parameters

Product Overview

First, the NFP-GM37-520-PEN is a 37mm DC gear motor with a photoelectric encoder. Therefore, it is suitable for drive systems that need speed feedback, direction control, and stable gearbox output.

In addition, the motor uses pure copper wire winding in the rotor. As a result, it can help reduce resistance and improve motor torque output.

Moreover, the photoelectric encoder provides basic pulse feedback. Therefore, users can use it for motion control systems that need more accurate speed detection.

Main Features

• First, pure copper winding: The rotor uses copper wire. Therefore, it can support better conductivity and stronger torque output.
• In addition, photoelectric encoder: The encoder provides pulse feedback. As a result, users can detect motor speed and direction.
• Also, wide voltage range: The motor supports 6V, 12V, and 24V DC options. In addition, this helps match different power systems.
• Next, CW and CCW rotation: The motor supports forward and reverse rotation. Therefore, it works well in two-way drive systems.
• Finally, multiple gear ratios: Users can choose different ratios for speed or torque needs. Moreover, higher ratios provide lower speed and higher torque.

Basic Motor Specifications

First, the table below shows the main motor and encoder data. Therefore, users can check voltage, shaft size, weight, connector type, encoder resolution, and application range before testing.

As a result, this model gives users a compact gear motor with encoder feedback, 6mm output shaft, and several voltage choices. Moreover, the optional connector types help match different control boards.

6V DC Performance Data

First, the table below shows the 6V DC version. Therefore, users can compare ratio, speed, current, torque, stall data, and gearbox length before choosing a model.

In addition, lower ratios provide higher output speed. However, higher ratios provide lower speed and higher torque.

Model: NFP-GM37-520-PEN, 6V DC

Note: All reduced no-load speeds have a tolerance of ±15%.

As a result, the 6V version covers speeds from 10rpm to 760rpm. Moreover, the 450:1 ratio gives the strongest rated torque in this table.

12V DC Performance Data

Next, the table below shows the 12V DC version. In addition, this version provides higher speed than the 6V version.

Moreover, the 12V version is useful for systems that need stronger output and higher rated current capacity. Therefore, it fits many robot and smart device projects.

Model: NFP-GM37-520-PEN, 12V DC

Note: All reduced no-load speeds have a tolerance of ±15%.

In short, the 12V version covers speeds from 21rpm to 1530rpm. Also, the high-ratio options provide stronger torque for slow drive tasks.

24V DC Performance Data

Finally, the table below shows the 24V DC version. In addition, this version keeps high speed while using lower rated current than the 12V version in many ratios.

As a result, users can choose it for 24V control systems. Moreover, it is suitable for compact equipment that needs stable speed feedback.

Model: NFP-GM37-520-PEN, 24V DC

Note: All reduced no-load speeds have a tolerance of ±15%.

In conclusion, the 24V version covers speeds from 21rpm to 1530rpm. Therefore, it is a good choice for 24V products that need speed feedback and stable torque.

DC Gear Motor with Photoelectric Encoder Outline Drawing

Gearbox Length by Ratio

First, the gearbox length changes with the reduction ratio. Therefore, users should confirm the ratio and gearbox length before mechanical design.

• First, 6.3:1 / 10:1: Gearbox length is 19mm.
• In addition, 18.8:1 / 30:1: Gearbox length is 21.5mm.
• Also, 50:1 / 90:1: Gearbox length is 24mm.
• Next, 150:1 / 270:1: Gearbox length is 26.5mm.
• Finally, 450:1: Gearbox length is 29mm.

Outline Drawing

First, the outline drawing below shows the motor body, gearbox, output shaft, and main dimensions. In addition, it helps users check the installation space before product design.

As a result, users can reduce assembly risk during prototype testing. Moreover, the drawing helps match brackets, couplers, and mounting holes.

Gearbox DC Motor Photoelectric Encoder Wiring Tips

Encoder Wiring Overview

First, the image below shows the photoelectric encoder wiring method. Therefore, users should check VCC, GND, and AB signal wires before power-on.

In addition, correct wiring helps protect the encoder and the control board. However, wrong polarity may damage the encoder.

Encoder Specifications

First, the table below shows the encoder data. Therefore, users can check encoder type, line speed, supply voltage, interface type, response frequency, base resolution, and MCU compatibility before wiring.

As a result, this photoelectric encoder is suitable for control boards with a hardware encoder interface. However, users should not use it with unsupported MCU systems.

Application Areas

Finally, this reduction gearbox DC carbon brush motor is useful for compact products that need speed feedback and controlled motion. For example, it can work in scooters, tracking cars, smart home devices, robots, gimbals, and tape cutters.

• First, smart self-balancing scooters: The encoder can help detect speed and direction.
• In addition, intelligent tracking cars: The motor can support controlled drive motion.
• Also, smart home appliances: The gearbox can provide compact low-speed output.
• Next, robots: The motor can support wheel drive, arm motion, and small joint control.
• Moreover, camera gimbals: The encoder can help improve motion feedback.
• Finally, electric tape cutters: The gear motor can provide controlled feeding and cutting motion.

Selection Notes

First, users should choose the voltage and gear ratio based on load, speed, and control needs. Also, users should confirm the encoder interface before wiring.

• First, for higher speed: Choose a lower gear ratio. Therefore, the output speed will be higher.
• In addition, for higher torque: Choose a higher gear ratio. As a result, the output speed will be lower, but torque will increase.
• Also, for 6V systems: Choose the 6V version when the driver and power supply use 6V DC.
• Next, for 12V systems: Choose the 12V version when the driver and power supply use 12V DC.
• Moreover, for 24V systems: Choose the 24V version when the driver and power supply use 24V DC.
• Finally, for encoder use: Use an MCU with a hardware encoder interface. Moreover, do not reverse VCC and GND.

In short, the NFP-GM37-520-PEN DC gear motor with photoelectric encoder is a good fit for products that need 6V, 12V, or 24V DC power, pure copper winding, encoder feedback, 37mm gearbox, and stable low-speed torque.
