37mm Metal Gear Motor Model NFP-GM37-545-EN

37mm Metal Gear Motor with Encoder Key Features

First, the NFP-GM37-545-EN is a high torque 37mm metal gear motor with an AB dual-phase magnetic Hall encoder. It supports 12V and 24V DC input, so users can select the right version for their power system.

Also, the motor uses a strong metal spur gearbox and a built-in cooling fan. Therefore, it can provide stable output, long service life, and reliable speed control for automation equipment, robots, and other electric devices.

• High torque metal spur gearbox
• 12V DC and 24V DC options
• AB dual-phase magnetic Hall encoder
• Wide output speed range
• Clockwise and counterclockwise rotation
• Built-in cooling fan
• 6mm output shaft
• XH2.54-6Pin encoder connector

NFP-GM37-545-EN Main Specifications

Next, the table below shows the main size, voltage, speed, power, wire, and weight data. In addition, these values help users check whether the motor fits the available space and power supply.

As a result, the motor can meet both low-speed, high-torque needs and faster drive needs. For example, a high gear ratio gives lower speed and more torque, while a low gear ratio gives higher output speed.

12V DC 19W Gear Motor Performance

First, the 12V DC version provides no-load speeds from 7rpm to 900rpm. Also, its rated torque changes with the gear ratio, so users can select the best balance of speed and torque.

In addition, the encoder pulse count rises with the gear ratio. Therefore, high-ratio models provide more output shaft pulses per turn and allow finer speed or position control.

As a result, the 12V model covers a wide range of speed and torque needs. For example, the 6.3:1 option gives 900rpm no-load speed, while the 810:1 option gives 7rpm no-load speed.

Also, all reduced no-load speeds have a tolerance of ±15%. Therefore, the actual speed may change because of load, voltage, temperature, and normal production tolerance.

24V DC 80W Gear Motor Performance

Next, the 24V DC version provides more power and higher speed. Moreover, it supports no-load speeds from 14rpm to 1,800rpm for both fast motion and high-torque drive systems.

Similarly, the motor uses the same wide gear ratio range. Therefore, users can select a suitable option without changing the basic motor size or encoder system.

As a result, the 24V model gives higher output speed than the 12V model at the same ratio. For example, the 10:1 version provides 1,150rpm no-load speed and 950rpm rated speed.

Also, all reduced no-load speeds have a tolerance of ±15%. Therefore, users should allow for normal speed change during system design and testing.

37mm Gear Motor Outline Drawing

First, the outline drawing below shows the motor body, gearbox, output shaft, mounting holes, and encoder cover. Therefore, engineers can check the available space before adding the motor to a machine or device.

In addition, the gearbox length changes with the selected ratio. As a result, users should check the gearbox length in the performance table before they confirm the final mounting space.

Miniature Geared Motor Encoder Connection

Next, the motor includes an AB dual-phase incremental magnetic Hall encoder. Also, the encoder can send speed and direction signals to a microcontroller, PLC, or motor control board.

Furthermore, the encoder supports both 3.3V and 5V DC power. Therefore, it can connect to many common control systems without a complex signal board.

Hall Encoder Specifications

First, review the encoder data before wiring the motor. In addition, make sure the power, ground, Hall A, and Hall B wires are connected to the correct controller pins.

As a result, the encoder can help measure speed, direction, travel distance, and shaft position. For example, a controller can compare target speed with actual speed and then adjust motor power.

Moreover, the AB signal can show the rotation direction. Therefore, the motor is suitable for closed-loop control, accurate movement, and repeatable positioning.

37mm Metal Gear Motor Applications

In addition, this 37mm metal gear motor is useful in systems that need high torque, stable speed, and encoder feedback. Therefore, it can serve many commercial, industrial, and consumer products.

• Office automation equipment
• Home automation systems
• Production automation equipment
• Medical equipment
• Security equipment
• Consumer electronics
• Aircraft models
• Automotive electronics
• Bank ATM machines
• Automatic banknote counters
• Banknote sorting machines
• Vending machines
• Copiers
• Video recorders
• Robotics
• Smart control systems

For example, the encoder can help a vending machine stop at the correct position. Similarly, it can help a robot measure wheel speed and travel distance.

In short, the NFP-GM37-545-EN combines a strong metal gearbox, wide speed range, high torque, and Hall encoder feedback. Therefore, it is a practical drive choice for both standard equipment and custom automation projects.
