38mm Metal Gear Motor Model NFP-CM6839-520

High Torque Gearbox Motor Data Sheets

First, the NFP-CM6839-520 is a 5V DC high torque gearbox motor for compact drive systems. Also, it supports CW and CCW rotation for forward and reverse motion.

In addition, this motor provides adjustable speed, low power consumption, and low noise operation. Therefore, it is useful for small devices that need stable output and energy-saving performance.

Moreover, the wiring is simple. The red wire is the positive pole, and the black wire is the negative pole. As a result, the output direction is clockwise under normal connection and reverses when polarity is changed.

Main Product Features

• First, long life: The motor is designed for stable use in compact drive systems.
• In addition, high torque: The gearbox helps provide stronger output at lower speed.
• Also, reversible rotation: Positive and negative wiring supports CW and CCW movement.
• Next, adjustable speed: Users can control speed based on the drive need.
• Moreover, low power use: The 5V motor supports low power consumption and compact control systems.
• Finally, low noise: The gearbox helps support quieter operation in small devices.

Basic Motor Specifications

First, the table below shows the main motor data. Also, it helps users check voltage, speed, current, input power, rotation, motor diameter, and shaft size before testing.

Note: All reduced no-load speeds have a tolerance of ±15%.

As a result, this motor gives a simple 5V gearbox motor solution for small drive products. Moreover, the 7mm shaft supports stable mechanical connection.

Reduction Gearbox Motor Outline Drawing

Motor Outline and Mounting Reference

First, the outline drawing helps users check the motor body, gearbox size, output shaft, and mounting space. Therefore, it is useful before sample testing and product design.

In addition, the compact structure helps save installation space. As a result, the motor can fit small robots, tools, smart devices, and custom drive units.

Outline Drawing and Design Benefits

• First, compact gearbox: The gear reduction structure helps save space.
• In addition, 33mm motor diameter: The body size is suitable for small machines.
• Also, 7mm shaft: The output shaft supports direct mechanical connection.
• Next, reversible wiring: The motor can support clockwise and counterclockwise output.
• Finally, clear dimensions: The drawing helps users design brackets, holders, and housings.

DC Motors Gearbox Characteristic Curve

Motor Test Data

First, the characteristic curve data helps users review current, input power, output power, speed, torque, and efficiency under different load points. Also, it is useful for selecting a suitable working range.

In addition, the motor reaches higher output power at the middle load point. Therefore, users should test the real load before final product design.

As a result, the table shows how speed decreases as torque and current increase. Moreover, it helps users avoid overload conditions during product testing.

Performance Selection Notes

• First, check voltage: Use a 5V DC power supply for this motor.
• In addition, check no-load speed: Use 203.6 rpm as the listed no-load reference.
• Also, check load current: Make sure the driver can support the current under real load.
• Next, check torque: Use the curve data to match the required torque range.
• Moreover, check efficiency: Avoid using the motor near the end point for long operation.
• Finally, test real load: Confirm current, speed, torque, temperature, and service life before production.

Applications and Selection Tips

Typical Applications

Finally, this 5V gear reduction motor is useful for small products that need low speed, high torque, and compact size. For example, it can work in small robots, smart devices, electric toys, DIY models, and mini automation units.

• First, small robots: The motor can drive wheels, arms, and small movement parts.
• In addition, smart devices: The compact body helps fit tight layouts.
• Also, electric toys: The 5V input is useful for small battery-powered systems.
• Next, DIY models: The motor can support custom test builds and prototypes.
• Moreover, mini automation units: The gearbox helps provide stable low-speed movement.
• Finally, small tools: The motor can drive compact mechanical parts.

Final Product Summary

In short, the NFP-CM6839-520 is a compact 5V high torque gearbox motor with 203.6 rpm no-load speed, 0.222A no-load current, reversible rotation, and a 7mm output shaft.

Moreover, the motor characteristic curve helps users check the working point before production. Therefore, users can choose a safer load range based on current, torque, speed, and efficiency.
