6mm Small Vibration Device – 12mm Type Model NFP-P0612-4410
$5.00
Discover the power of the 6mm Small Vibration Device, featuring a coreless dc motor for impressive performance. Enhance your projects today!
107 in stock
| Quantity | Price | Discount |
|---|---|---|
| 1 - 99 | $5.00 | 0% |
| 100 - 999 | $1.50 | 70% |
| 1000+ | $1.16 | 76.80% |
3V DC 6mm Mini Vibration Motor Model NFP-P0612-4410 Parameters
3V coreless dc motor with an eccentric rotating mass, erm vibration motors.
| Motor Model: | NFP-P0612-4410 |
|---|---|
| Rated Voltage: | 3V DC |
| Load Speed: | 11,000rpm ± 3,000rpm |
| Load Current: | ≤ 80mA |
| Start Voltage: | ≤ 0.8V DC |
| Stall Current: | ≤ 180mA |
| Rotation: | CW |
| Resistance at 100V: | >5MΩ |
| End Play: | 0.05mm – 0.3mm |
| Motor Diameter: | Ø6.0mm ± 0.05mm |
| Motor Length: | 12.2mm ± 0.2mm |
| Total Length: | 18.3mm ± 0.3mm |
| Ecc. mass length: | L – 4mm |
| Ecc. Weight Radius: | R – 3mm |
3V DC Vibration Motor Outline Drawing
Keywords:
small vibration motor, vibration motor in phone, haptic vibration motor, tiny vibration motor
Payment:
1.Payment methods : Paypal, T/T
Shipping:
1.Delivery: DHL/FedEx 3-5 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.
FAQ
Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It’s better to offer application prototype drawings to us if possible.
Q: What’s your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.
Q: What’s the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.
1.Payment methods : Paypal, T/T
Shipping:
1.Delivery: DHL/FedEx 3-5 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.
FAQ
Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It’s better to offer application prototype drawings to us if possible.
Q: What’s your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.
Q: What’s the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.
