12mm Small Vibration Device – 20mm Type Model NFP-P1220

$8.50

(5 customer reviews)

10mm Vibration Motor Small Volume Price (USD)

QTY BREAK UNIT PRICE
1+ $8.50
100+ $6.25
1,000+ $4.38

Contact us for a quotation for production quantities, customizations and integration.

12mm Programmable Vibration Motor Parameters


Amazing powerful vibration motor. 12mm diameter, 20mm length.

Motor Model: NFP-P1220
Rated Voltage: 3.0V DC
Ecc. Weight Radius: R – 5.5mm
Ecc. Weight Length: L – 6.0mm
Load Current: ≤450mA
Load Speed: 11,000 ± 2,000rpm
Start Voltage: ≤0.8V
Stall Current: ≤3,000Ma
Rotation: CW
Resistance:  @100V, >5MΩ
End Play: 0.05mm – 0.3mm
Motor Body Length: 20.8mm ± 0.2mm
Motor Overall Length: 28.1mm ± 0.3mm
Motor Diameter: 12.0 ± 0.05mm
Amplidtude: 25G



25G Miniature Vibration Motor Outline Drawing


12mm-eccentric-rotating-mass-vibration-motor-outline-drawing

Keywords:
erm vibration motor, eccentric rotating mass vibration motor, micro vibration motor

Payment:
1.Payment methods : Paypal, T/T

Shipping:
1.Delivery: DHL/FedEx 3-5 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.

FAQ
Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It’s better to offer application prototype drawings to us if possible.

Q: What’s your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.

Q: What’s the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.
