4mm Small Vibration Device – 11mm Type Model NFP-P0411-723
$3.00
Unlock creativity with our 4mm Small Vibration Device, perfect for robots and projects! Get excited about making vibrobots today!
| Quantity | Price | Discount |
|---|---|---|
| 1 - 99 | $3.00 | 0% |
| 100 - 999 | $1.10 | 63.33% |
| 1000+ | $0.95 | 68.33% |
4mm Micro Vibration Motors Small/Bulk Order Support
4 mm diameter, 8 mm length small vibration motors widely used for pager, phones. These little vibration motors have offset weights that make them vibrate when they’re powered.
You can use these tiny vibration motors in eggbot kit. They’re also the perfect thing for making vibrobots, BEAM bots, and other little robots! They have wire laeds attached that are color coded and have 2 mm pre-stripped and tinned ends.
| Motor Model | NFP-P0411-723 |
|---|---|
| Rated Voltage: | 3V DC |
| Motor Diameter: | 4.2mm ± 0.2mm |
| Mounting Bracket Diameter: | 4.4mm ± 0.2mm |
| Total Length: | 14.9mm ± 0.3mm |
| Motor Length: | 11.4mm ± 0.2mm |
| End Play: | 0.05mm – 0.3mm |
| Resistance 100V: | >5MΩ |
| Rotation: | CW |
| Stall Current: | <180mA |
| Start Voltage: | <1.2V DC |
| Load Speed: | 21,000rpm ± 15% |
| Load Current: | <100mA |
| Ecc. Weight Radius: | 2.0mm |
| Ecc. Weight Length: | 3.0mm |
| Amplitude: | 0.5G |
4mm Tiny Vibration Motor PCB Through Hole Type Outline Drawing
Ultra-Compact Design for Space-Saving Applications – Measuring just 4mm in diameter and 11mm in length, this small vibration motor is perfect for devices where space is at a premium. Ideal for wearable technology, medical devices, and miniature electronics that require a compact vibration solution.
PCB Through-Hole Mounting for Easy Integration – Featuring a PCB through-hole design, the NFP-P0411-723 is easy to mount directly onto circuit boards. This simplifies the assembly process and ensures a secure connection, enhancing the reliability of your product.
Keywords:
4mm vibration motor, small vibration motor, PCB through-hole motor, NFP-P0411-723, 11mm length vibration motor, micro vibration motor, PCB mount vibration motor, miniature vibration motor
1.Payment methods : Paypal, T/T
Shipping:
1.Delivery: DHL/FedEx 3-5 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.
FAQ
Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It’s better to offer application prototype drawings to us if possible.
Q: What’s your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.
Q: What’s the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.
