6mm Small Vibration Device – 12mm Type Model NFP-P0612-PCB

$5.00

(3 customer reviews)

3V Vibration Motors Small Volume Price (USD)

QTY BREAK UNIT PRICE
1+ $5.00
100+ $1.35
1,000+ $1.05

Contact us for a quotation for production quantities, customizations and integration.

6mm 3V Vibration Motor Model NFP-P0612 To PCBs


Small vibration motor use for wearable device. Mounting method is

Motor Model: NFP-P0612 Big Mass
Motor Diameter: 6mm
Motor Length: 12mm
Rated Voltage: 3V DC
Rated Speed: 8,000rpm
Eccentric Mass Length: 4mm
Nominal Amplitude Vibe Force: 2.60G



Motor Model: NFP-P0612 Small Mass
Motor Diameter: 6mm
Motor Length: 12mm
Rated Voltage: 3V DC
Rated Speed: 11,000rpm
Eccentric Mass Length: 3mm
Nominal Amplitude Vibe Force: 2.75G



Cylindrical Vibration Motor ERM Type Outline Drawing


6mm-pcb-mount-motor-outline-drawing

Keywords:
pcb mount motor, vibration motor, vibrating motor, vibrator motor, erm motor, eccentric rotating mass vibration motor, pager motor

Payment:
1.Payment methods : Paypal, T/T

Shipping:
1.Delivery: DHL/FedEx 3-5 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.

FAQ
Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It’s better to offer application prototype drawings to us if possible.

Q: What’s your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.

Q: What’s the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.

Still can’t find ideal motors?


The electrical parameters of the motor can be adjusted. For example, the two main factors determining the vibration force: the size of the pager motor eccentric mass and the speed requirement. , voltage, current can be adjusted according to customer needs. Some encapsulated vibration motors adding terminals connectors, which are our customized products according to different customers. You can also contact us in the bottom contact form to ask for your needs.

If you want a custom lead wire connection of the water resistant vibration motors. Such as alternate lead wire length & strip lengths, with a connector (e.g. Molex, JST). You can contact us from the footer form, tell us your need. Any problems will be taken seriously and will be answered professionally, so pls do not hesitate to contact us by the footer form.

Free Shipping Site-wide When You Spend More Than $150

Using The Following Coupon When You’re Going To The Checkout

3 reviews for 6mm Small Vibration Device - 12mm Type Model NFP-P0612-PCB

  1. Gorka Sadaba

    These vibration motors worked great for my some applications, and I didn’t have any dead motors. If I could change one thing it would be the length of wire exposed on the end as the wires are thin and a little touchy to strip.

  2. frank Kelly

    This cylindrical vibration motor is just right. I bought it for wearable device. When ordering, one should be careful to order the correct speed. I originally ordered a 2000 rpm motor, thinking the motor could run in 2000rpm, as described. If you buy the 2000 rpm unit, it will run at 2000rpm or slower. I then bought the 8,000rpm unit, and it is perfect.

  3. Erik Fong

    The vibrating motor came quickly, the vibration motor of quality is excellent😊
