6mm Small Vibration Device – 15mm Type Model NFP-P0615-PCB


(6 customer reviews)

3V Vibration Motors Small Volume Price (USD)

1+ $5.00
100+ $1.35
1,000+ $1.05
5,000+ $0.95

Contact us for a quotation for production quantities, customizations and integration.


6mm Vibration Motor Model NFP-P0615 With Through-Hole Pins

Most of the pager motors use miniature Eccentric Rotating Masses. ERM pager motors rely on the rotation of an unbalanced load to create vibration effects and are more recently being used for haptic feedback as well as vibration alerting.

Motor Model NFP-P0615-PCB
Motor Diameter 6mm
Motor Length 15mm
Rated Voltage 1.5V DC
Rated Load R – 3mm * L – 4.5mm
Rated Speed 8,500 ± 1,500rpm
Rated Current 26mA
Rotation CW/ CCW
Life Test 8s on, 8s off, 20,000cycles
Nominal Amplitude Vibe Force 1.50G


Cylindrical Vibration Motor ERM Type Outline Drawing

Miniature ERM Motors are used almost exclusively for vibration alerting and haptic feedback. Therefore, in essence any machine or application that uses sound or light to offer user / operator feedback could be further enhanced with a vibration motor.


vibration motor, vibrating motor, vibration motors, vibrator motor, mini vibration motor, small vibration motor, micro vibration motor, erm vibration motors

1.Payment methods : Paypal, T/T

1.Delivery: DHL/FedEx 3-5 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.

Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It’s better to offer application prototype drawings to us if possible.

Q: What’s your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.

Q: What’s the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.

Free Shipping Site-wide When You Spend More Than $150

Click The Following Button To Copy the Coupon Code When You’re Going To The Checkout

Still can’t find ideal motors?

Get A Quote Within 8 Hours Contact Now! Any question about Micro DC Motor, Spec, Data-Sheet, Quote…

If you want a custom lead wire connection of the water resistant vibration motors. Such as alternate lead wire length & strip lengths, with a connector (e.g. Molex, JST). You can contact us from the footer form, tell us your need. Any problems will be taken seriously and will be answered professionally, so pls do not hesitate to contact us by the footer form.

6 reviews for 6mm Small Vibration Device - 15mm Type Model NFP-P0615-PCB

  1. Peter Shefte

    Pretty nice vibration motor, all the motors were definitely brand new, and they were easy to use and provided an excellent vibration strength to make the robots move.👍👍👍

  2. Jay Gupta

    These are decently built vibration alert motors. While rated at one point 1.5 volts direct current I have ran them at lower voltage sometimes. The erm vibration motors have a strong magnetic field so keep them an appropriate distance from any magnetically sensitive components.

  3. Tony kelly

    This erm vibration motor has been working well. According to my cell phone’s sound app control the bristlebot, before and after the motor is energized. It appears to be a good value for the cost.

  4. Ari Sinisalo

    These diy vibrating motors seem to be popular in making “Bristlebots” by my kids.

  5. meghbshah

    Small quality 3v motor 1,2000rpm 80mm With Connector, that performs to specifications. These were used on brushbots and bristlebots. They ran great.

  6. Lev Ilyayev

    6mm small vibration motor, They were easy to use and provided an excellent vibration motor strength to make the robots move.
