6mm Coreless DC Motor – 16mm Type Model NFP-D0617
$7.00
Unleash speed and efficiency with the 6mm high speed coreless motor 2.5V/3V. The coreless design ensures quick acceleration and low inertia. Explore now!
Notice: this motor model need to make new ones that would take extra 2-3weeks.
| Quantity | Price | Discount |
|---|---|---|
| 20 - 49 | $7.00 | 0% |
| 50 - 99 | $5.60 | 20% |
| 100 - 499 | $3.50 | 50% |
| 500 - 999 | $1.20 | 82.86% |
| 1000+ | $0.99 | 85.86% |
6mm Micro Coreless Motor Model NFP-D0617, 3.4V DC, 53,000RPM Parameters
The 6mm micro coreless motor NFP-D0617 works with low-voltage DC power. It is suitable for small products that need high speed, fast response, and compact size.
First, this motor can run at very high speed. Also, its coreless design helps reduce rotor inertia. As a result, the motor can start, stop, and change speed quickly.
In addition, the NFP-D0617 is useful for medical devices, robotics, drones, and small consumer electronics. Therefore, it is a good choice for compact products that need quick motion.
Main Product Features
- First, high speed: The no-load speed can reach up to 54,000rpm.
- In addition, low-voltage power: The motor works with 2.5V and 3V DC options.
- Also, compact size: The 6mm body fits small device spaces.
- Next, high torque output: The motor provides strong torque for its small size.
- Finally, coreless design: It helps reduce wear, heat, and rotor inertia.
6mm Micro Coreless Motor Performance Data
Next, the table below helps users compare voltage, speed, current, torque, power, efficiency, and weight. Therefore, it is easier to choose the right NFP-D0617 option for a small device.
| Model | NFP-D0617-1-2.5 | NFP-D0617-1-3.0 |
|---|---|---|
| Voltage | 2.5V | 3V |
| Terminal resistance | 0.5Ω | 0.9Ω |
| No-load-speed | 54,000rpm | 48,000rpm |
| No-load-current | ≤120mA | ≤75mA |
| Stall torque | CW19.68g.cm | CW17.87g.cm |
| Stall current | 4,990mA | 3,300mA |
| Max output power | 2.727W | 2.2W |
| Max efficiency | 66% | 67% |
| Torque constant | 4g.cm/A | 5.5g.cm/A |
| Rotor inertia | <0.03g.cm² | <0.03g.cm² |
| Weight | 2g | 2g |
Also, the NFP-D0617-1-2.5 gives higher no-load speed and higher output power. However, the NFP-D0617-1-3.0 gives lower no-load current and higher max efficiency.
Therefore, users can choose the 2.5V model for more speed and power, or choose the 3V model for lower current and better efficiency.
Buy Coreless DC Motor Dimensions
First, the coreless structure helps reduce electromagnetic noise and iron loss. As a result, the motor can run with higher efficiency and lower heat.
In addition, lower heat is useful for long running time. Therefore, this motor can support small devices that need stable operation.
Coreless Design Benefits
- First, fast response: The low rotor inertia helps the motor react quickly.
- In addition, higher efficiency: The coreless design helps reduce power loss.
- Also, lower heat: The motor can reduce heat during operation.
- Next, smooth running: The structure helps reduce vibration.
- Finally, long service life: Less wear can help improve motor life.
Terminal Wire Note
Next, terminal wires can be added if needed. However, customers need to send an email for extra instructions, and extra fees will apply.
Note: The MOQ for terminal wires is 100pcs. Also, by default, only the wiring model is supplied without any terminals.
Customization Options
In addition, the NFP-D0617 can be customized for specific needs. For example, users can discuss different shaft lengths, gear options, and voltage ratings.
As a result, engineers can match the motor to different product designs more easily. Therefore, it is useful for both sample testing and custom projects.
- Custom shaft length
- Gear option support
- Voltage option support
- Terminal wire option
- Small batch project support
Typical Applications
Finally, this motor is widely used in small products that need speed, torque, and compact size. For example, it can be used in medical tools, robotic arms, drones, and portable devices.
- Medical instruments
- Robotic arms
- Drones
- Portable devices
- Small consumer electronics
- Compact battery-powered products
In short, the NFP-D0617 is a good fit for compact products that need high speed, fast response, high efficiency, and low weight.
Keywords: micro coreless motor, buy coreless dc motor
1.Payment methods : Paypal, T/T
Shipping:
1.Delivery: DHL/FedEx 3-5 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.
FAQ
Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It’s better to offer application prototype drawings to us if possible.
Q: What’s your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.
Q: What’s the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.
