6mm Mini DC Gear Motor – 17mm Type Model NFP-609-26.45-0675 Standard Shaft
$3.66
Order Low Volume Pricing (USD)
| QTY BREAK | UNIT PRICE |
|---|---|
| 1+ | $3.66 |
| 10+ | $3.16 |
| 50+ | $3.11 |
| 100+ | $3.01 |
| 500+ | $2.66 |
| 1,000+ | $2.41 |
Contact us for a quotation for production quantities, customizations and integration.
6mm Mini DC gear motor -17mm type motor model NFP-609-26.45-0675 performance
| Motor model: | NFP-609-26.45-0675 |
|---|---|
| Rated voltage: | 3V DC |
| Start voltage | ≤1V DC |
| No-load current | 50mA |
| Stall current | ≤230mA |
| Output speed | 1200±120rpm |
| Work torque | 27g.cm |
| Ratio | 26.45 |
| No-load noise | <48db |
– Above specifications are subject to change without notice, just for reference and customizable according to requirements – Plastic output shaft is better to be used in those conditions need small torque, or of no radial load, or via coupling joint
6mm Planetary DC Gearmotor Outline Drawing
Typical Application:
These 6mm precision gear motors are widely used in electronic rotating mascaras, robotic mechanisms, medical equipments, etc. The gearbox is made of plastic material, RoHS compliant. The gear ratio can be adjusted as per buyers’ requirements
Keywords:
geared motors uk, hobby motors and gears, motor gearbox, micro gear motor with encoder, dc motor gearbox
Development Samples:
Sampling quantities for stocked models are available for ordering directly from us online.
Engineering & Manufacturing:
Please contact one of our Sales Engineers for a quotation for production and consultation for customization and integration services.
Payment:
1.Payment methods : Paypal, T/T
Shipping:
1.Delivery: DHL/FedEx 3-5 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.
FAQ
Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It’s better to offer application prototype drawings to us if possible.
Q: What’s your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.
Q: What’s the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.
