6mm Mini DC Gear Motor – 19mm Type Model NFP-609-136-0675 Standard Shaft


(4 customer reviews)

Order Low Volume Pricing (USD)

1+ $3.82
10+ $3.32
50+ $3.27
100+ $3.17
500+ $2.82
1,000+ $2.57

Contact us for a quotation for production quantities, customizations and integration.


3D Drawing

6mm Mini DC Gear Motor Model NFP-609-136-0675

Motor model: NFP-609-136-0675
Rated voltage: 3V DC
Start voltage: ≤1V DC
No – load current: 60mA Max
Stall current: ≤230mA
Output speed: 242 ± 5rpm
Work torque: ≤120g.cm
Ratio: 136.02
No-load noise: <48db

– Above specifications are subject to change without notice, just for reference and customizable according to requirements. – Plastic output shaft is better to be used in those conditions need small torque, or of no radial load, or via coupling joint.

Miniature DC Gearmotors Outline Drawing


6mm Mini DC Gear Motor Mass Production


Typical Application:
These 6mm precision gear motors are widely used in electronic rotating mascaras, robotic mechanisms, medical equipments, etc. The gearbox is made of plastic material, RoHS compliant. The gear ratio can be adjusted as per buyers’ requirements

custom gear motors, micro planetary gear motor, custom gearmotors, custom oem gear motors, dc gear motor custom, custom gear motor manufacturers

1.Payment methods : Paypal, T/T

1.Delivery: DHL door to door 3-4 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.

Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It’s better to offer application prototype drawings to us if possible.

Q: What’s your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.

Q: What’s the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.

Still can’t find ideal motors?

The electrical parameters of the motor can be adjusted. For example, the two main factors determining the vibration force: the size of the pager motor eccentric mass and the speed requirement. , voltage, current can be adjusted according to customer needs. Some encapsulated vibration motors adding terminals connectors, which are our customized products according to different customers. You can also contact us in the bottom contact form to ask for your needs.

If you want a custom lead wire connection of the water resistant vibration motors. Such as alternate lead wire length & strip lengths, with a connector (e.g. Molex, JST). You can contact us from the footer form, tell us your need. Any problems will be taken seriously and will be answered professionally, so pls do not hesitate to contact us by the footer form.
