6mm Small Vibration Device – 10mm Type Model NFP-0610KJ-055100-2530

$3.00

(3 customer reviews)

Order Low Volume Pricing (USD)

QTY BREAK UNIT PRICE
1+ $3.00
100+ $1.20
1,000+ $0.99



DATA SHEET

Contact us for a quotation for production quantities, customizations and integration.

6mm Vibration Motor PCB Through Hole Parameters


All pager motors use miniature Eccentric Rotating Masses, and hence the tend to be abbreviated ‘ERM motors’. ERM pager motors rely on the rotation of an unbalanced load to create vibration effects and are more recently being used for haptic feedback as well as vibration alerting feedback.

Motor Model: NFP-0610KJ-055100-2530
Motor Diameter: 6mm
Motor Thickness: 10mm
Rated Voltage: 3.0V DC
Load Speed: 11,000rpm
Load Current: 40mA
Nominal Amplitude Vibe Force: 1.30G



6mm Cylindrical Vibration Motor Outline Drawing


6mm-eccentric-rotating-mass-vibration-motor

Keywords:
vibration motor, motor vibrations, mini vibration motor, micro vibration motor, dc vibration motor, erm motor, powerful vibration motor

Payment:
1.Payment methods : Paypal, T/T

Shipping:
1.Delivery: DHL/FedEx 3-5 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.

FAQ
Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It’s better to offer application prototype drawings to us if possible.

Q: What’s your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.

Q: What’s the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.

Still can’t find ideal motors?


The electrical parameters of the motor can be adjusted. For example, the two main factors determining the vibration force: the size of the pager motor eccentric mass and the speed requirement. , voltage, current can be adjusted according to customer needs. Some encapsulated vibration motors adding terminals connectors, which are our customized products according to different customers. You can also contact us in the bottom contact form to ask for your needs.

If you want a custom lead wire connection of the water resistant vibration motors. Such as alternate lead wire length & strip lengths, with a connector (e.g. Molex, JST). You can contact us from the footer form, tell us your need. Any problems will be taken seriously and will be answered professionally, so pls do not hesitate to contact us by the footer form.

Free Shipping Site-wide When You Spend More Than $150

Using The Following Coupon When You’re Going To The Checkout

3 reviews for 6mm Small Vibration Device - 10mm Type Model NFP-0610KJ-055100-2530

  1. ALAN V. D’SOUZA

    Vendors provide a mechanical diagram (depicting hole dimensions and spacing) to me. I trust a diagram more than my ruler. The dc vibration motor kept running for 30 minutes and I stopped it. it seems to be of good quality and has sufficient torque for my application.

  2. John Trotter

    Small 3V vibrating dc motor, really tiny but can see obviously that no scratches and no rusty spot on the surface, the used metal material was good. With very low noise, its performance is perfect.👍

  3. Jeff Guard

    3 volt 6mm diameter electric vibrating motor works as advertised. Easy to solder. Vibrating motor of quality seems great.
