6mm Small Vibration Device – 15mm Type Model NFP-P0615-4302

$3.00

(5 customer reviews)

Enhance your devices with the 6mm Small Vibration Motor for precise haptic feedback and effective vibration alerts. Order yours now!

28 in stock

USDUSD
EUREUR
GBPGBP
JPYJPY
HKDHKD
QuantityPriceDiscount
1 - 99$3.000%
100 - 999$2.2525%
1000+$1.4751%

6mm Cylindrical Vibration Motors Small Dimension Big Amplitude


First, most pager motors use miniature eccentric rotating masses. Consequently, ERM pager motors rely on the rotation of an unbalanced load to create vibration effects. Therefore, they are increasingly used for haptic feedback as well as vibration alerting. In addition, miniature ERM motors serve almost exclusively for vibration alerting and haptic feedback applications.

Key details:

  • Compact 6mm cylinder design
  • Provides strong amplitude vibration
  • Features fine metal construction
Model Value
Rated Voltage: 3.0V DC
Motor Diameter: 6mm ± 0.05mm
Total Length: 21.3mm ± 0.3mm
Motor Body Length: 15.4mm ± 0.2mm
End Play: 0.05mm – 0.3mm
Resistance: > 5M?
Rotation: CW
Stall Current: ≤130mA
Start Voltage: 0.8V DC max
No-load Speed: 10,000rpm ± 15%
No-load Current: ≤80mA
Ecc. Weight Radius: 3mm
Ecc. Weight Length: 4.5mm
Amplitude: 2.85G
Wire Length: 25mm
Note: all reduced no-load speeds have a tolerance of ±15%.



3 Volt Vibration Motor 10,000RPM Dimensions


Therefore, any machine or device that uses sound or light to offer user feedback can be improved with a 6mm Small Vibration Motor. For example, these little motors have offset weights that make them vibrate when they spin. Also, they resemble traditional pager motors, but they are bigger and stronger.

What can you do with them? Specifically, engineers use motors just like this for the engraving attachment in many maker kits.

615-3v-small-vibration-motor-dimensions

If you want to get this motor but without the eccentric part, check out the 6mm Coreless Micro DC Motor. Furthermore, you can browse all similar coreless DC motors without eccentric mass on the Coreless Brushed DC Motors page.

Related Motor Models & Options

For application needs requiring alternative driving mechanisms, operating voltages, or structural designs, consider these complementary solutions:

Keywords: small vibration motor, 6mm vibration motor, micro dc vibration motor, haptic feedback motor, pager motor, mini vibration motor

Payment:
1.Payment methods : Credit Card, Paypal, T/T, Google Pay, Apple Pay...
Shipping:
1.Delivery: DHL/FedEx 3-5 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.
FAQ
Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It's better to offer application prototype drawings to us if possible.
Q: What's your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.
Q: What's the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.
