75W 3A 6V-24V DC Brushless Motor Controller Board Model NFP-BMLC-175A

$15.00

(1 customer review)

Optimize your industrial applications with our Brushless Motor Controller Board, compatible with various voltage systems. Get yours and enhance efficiency!

USDUSD
EUREUR
GBPGBP
JPYJPY
HKDHKD
Category: Brand:

Brushless Motor Control Board 75W Parameters


Precision 75W DC brushless motor controller compatible with 6V, 12V, and 24V systems. Ideal for high-power fan motors, offering stepless speed regulation and efficiency for industrial and commercial applications.

Driver Model NFP-BMLC-175A
Driver Type 3 phases
Operating Voltage 6V – 24V DC
Operating Current ≤3.0A
Rated Power 50W
Peak Power 75W
Weight 17.3g



Variable Speed Brushless Motor Controller Interface


U、V、W connect to brushless motor.

VCC、GND external DC power supply, VCC positive, GND negative. Voltage between 6V – 24V.

Do not connect motors with mismatched power levels.

Support 2-5S small power brushless motor speed regulation.

NFP-BL2450R-6v-12v-24v-motor-pwm-controller-interface



24V BLDC Fan Speed Controller Outline Drawing


Energy Efficiency: This small brushless motor controller is optimized for minimal energy loss, providing consistent performance while reducing power consumption. Ideal for operations where efficiency and power management are critical.

NFP-BL2450R-controller-bldc-fan-driver-dimension

Keywords:
dc fan motor driver board, high power bldc fan driver, bldc motor driver for cooling fans

Payment:
1.Payment methods : Paypal, T/T
Shipping:
1.Delivery: DHL/FedEx 3-5 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.
FAQ
Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It’s better to offer application prototype drawings to us if possible.
Q: What’s your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.
Q: What’s the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.
