7mm Coin Vibration Motor – 2mm Type Model NFP-FLAT-C0720
$3.00
Experience haptic feedback with the compact 7mm coin vibration motor that works silently in your lightweight devices. Order engineering samples today!
| Quantity | Price | Discount |
|---|---|---|
| 1 - 99 | $3.00 | 0% |
| 100 - 499 | $1.20 | 60% |
| 500 - 999 | $0.99 | 67% |
| 1000+ | $0.85 | 71.67% |
7mm Coin Vibration Motor For Light Wearable Devices
First, this 7mm coin vibration motor runs on 3V DC power, so you do not need a driver IC. Therefore, engineers can easily mount the NFP-C0720 in light wearable devices. In addition, it operates silently while giving strong vibration alerts or haptic feedback. We also offer test samples before you place a mass order.
| Parameter | Value |
|---|---|
| Model | NFP-C0720B / P/N C0720B015F |
| Diameter | 7mm ± 0.1mm |
| Thickness | 2.1mm ± 0.1mm |
| Rated Voltage | 3V DC |
| Voltage Range | 2.7V – 3.3V |
| No-load Speed | 10,000rpm min |
| Rated Current | 85mA max |
| Start Voltage | 2.3V DC max |
| Rotation | CW, CCW |
| Lead Wire Length | 50mm |
| Operating Temp | -20~60°C |
| Storage Temp | -30~70°C |
| Vibration Amplitude | 0.8G |
Flat Vibration Motor Outline Drawing
We designed this pancake motor for small products that need tactile alerts. Because it creates a 0.8G vibration force, it fits best in light devices placed against the skin. For example, you can drive this motor with simple DC voltage or a PWM signal.
Pancake Vibration Motor Options
Although a driver IC is not necessary, you can use one to create various haptic effects. Also, we provide custom foam pads and wire lengths for your project needs. For instance, major brands use these motors in fitness trackers and medical devices.
- Custom wire length and lead connectors
- Self-adhesive foam pad options for easy mounting
- Low power draw for battery devices
7mm Tiny Vibration Motor Uses
Next, this mini vibration motor powers the Pavlok 3 Pro wearable. Therefore, the device uses vibration alerts to help users break bad habits effectively.
Related Motor Models & Options
If you require alternative setups or options for your project, consider these choices:
- For standard micro vibration needs, check out the 10mm Flat Vibration Motor Model NFP-C1027B002F which provides stronger haptic feedback in a slightly larger form factor.
- If you need an encapsulated design with higher waterproof protection, explore the Waterproof Vibration Motor Model NFP-0724.
- For linear drives instead of eccentric rotating mass (ERM), see the Linear Resonant Actuator Model NFP-LRA-0832 for faster response times.
Keywords: coin vibration motor, 7mm flat vibration motor, 7mm pancake vibration motor, mini coin vibration motor, 7mm ERM motor
Payment:
1.Payment methods : Credit Card, Paypal, T/T, Google Pay, Apple Pay...
Shipping:
1.Delivery: DHL/FedEx 3-5 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.
FAQ
Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It's better to offer application prototype drawings to us if possible.
Q: What's your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.
Q: What's the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.
