7mm Small Vibration Device – 16mm Type Model NFP-P0716-0-1515
$5.00
7mm eccentric rotating mass vibration motor delivers smooth, low-noise vibration for wearables, haptics, handheld devices, robotics and compact electronics.
80 in stock
| Quantity | Price | Discount |
|---|---|---|
| 1 - 99 | $5.00 | 0% |
| 100 - 999 | $0.99 | 80.20% |
| 1000+ | $0.95 | 81% |
Cylinder Coreless Vibrating Motor Model Performance
7mm x 16mm | 3.0 V DC | ERM Vibration Motor Used For Massager Equipment. These little motors have offset weights that make them vibrate when they spin. Like our pager motors, but bigger and stronger.
What to do with them? We use motors just like this (but with longer leads) for the engraving attachment for the Eggbot kit.#They’re also the perfect thing for making vibrobots, BEAM bots, and other little robots!
| Motor Model: | NFP-P0716-0-1515 |
|---|---|
| Rated Voltage: | 3.7V DC |
| Motor Diameter: | 7mm ± 0.05mm |
| Total Length: | 22.3mm ± 0.3mm |
| Motor Body Length: | 16.5mm ± 0.2mm |
| End Play: | 0.05mm – 0.3mm |
| Resistance: | > 5MΩ |
| Rotation: | CW |
| Stall Current: | ≤900mA |
| Start Voltage: | ≤0.8V DC |
| Load Speed: | 17,000 ± 2,000rpm |
| Load Current: | 175mA |
| Ecc. Weight Radius: | 3mm |
| Ecc. Weight Length: | 5mm |
| Amplitude: | 7.50G |
| Motor Resistance: | 5.1Ω |
Eccentric Rotating Mass Vibration Motor Outline Drawing
They have 30 mm wire leads attached that are color coded and have 2 mm pre-stripped and tinned ends.Connectors and rubber sleeves / boots may be added to most leaded parts. Eccentric Rotating Mass vibration motors, also commonly known as ERMs or pager motors, make up our main product lines and have been our core business.
They shot to popularity with use in pagers and have grown alongside the mobile / cell phone industry, where they are still extremely popular in smartphones. Now there are a wide range of applications that use these tiny vibration motors to offer vibration alert notifications and haptic feedback.
7mm Pager Motor – This small motor is used in pagers and other small electronic devices. It is a high-quality product that provides reliable performance. It is designed to be reliable, efficient, and cost-effective.
If you to get this motor but without the eccentric part, you can check the following link:
https://www.nfpmotor.com/3-3-7v-dc-7mm-mini-micro-coreless-motor-16mm-model-nfp-d0716
All similar corelesss dc motors without eccentri mass:
https://www.nfpmotor.com/coreless-brushed-dc-motors
Keywords:
pager motor, 7mm motor, small motor, high-quality motor, reliable performance, efficient, and cost-effective
1.Payment methods : Paypal, T/T
Shipping:
1.Delivery: DHL/FedEx 3-5 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.
FAQ
Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It’s better to offer application prototype drawings to us if possible.
Q: What’s your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.
Q: What’s the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.
Kristi Reed –
This motor is a gem! At only 7mm, it fits easily even in tight spaces, and the vibrations are smooth. It’s also reliable and durable.
Clark Gurner –
I got these as replacements for my instrument, and they work amazingly well. A high-quality product at an affordable price.🫡
Jørn Christensen –
These erm motors are strong and powerful for their size. Just what I needed to build therapy stimulators. Runs great using 1 AA battery. I try to make it rechargeable. : )
Kirby –
Pretty nice micro pager motors. It is ok until it works, and the connection is strong. But once it is detached, there is no way to rework on that, well I broke one carelessly☹️… Apply silicon glue before you work with them, in a word they were not bad.
Andy Jones –
Great little eccentric rotating mass vibration motor. I’m using it to swivel spray arm robot and it has no problem swinging them back and forth. Needed small motor for project! Just the right size.
Justin Marsh –
Excellent 3.7v tiny erm vibration motor for price. Lightweight but with very good precision. Got them installed in our new application and the test results are ideal.😇
Tobias Ackermann –
This pancake vibration motor is good for school project. Perfect .
