12mm Small Vibration Motor – 15mm Type Model NFP-FF-N20-6048A
$3.00
Discover the versatility of the N20 copper head vibration motor! Delivering great performance in a small size, it is a must-have for creators.
| Quantity | Price | Discount |
|---|---|---|
| 1 - 99 | $3.00 | 0% |
| 100 - 999 | $1.50 | 50% |
| 1000+ | $0.99 | 67% |
Small Vibrating Motor NFP-FF-N20-6048A Parameters
This small vibration device offers big vibration amplitude in a compact dimension. Two solder terminals “+” and “-” can be welded with connection wires.
| Motor Model: | NFP-FF-N20-6048A |
|---|---|
| Motor Diameter: | 12.0mm |
| Motor Length: | 15.0mm |
| Rated Voltage: | 3.7V DC |
| Voltage Range: | 3.0V – 4.5V |
| Start Voltage: | 1.2V DC |
| Rated Load: | Eccentric 6.0mm * 4.0mm |
| Load Speed: | 11,000 ± 10%rpm |
| Load Current: | 95mA max |
| Amplitude: | 8G |
3.7V DC Vibration Motor Outline Drawing
There are two holes in front of motors for mounting to a bracket. This kind of small d c vibration motor is widely used for adult toys, leg, massager, game controller, mixer, vibrating feeders.
Applications
Used in beauty equipment, massage goggles, massage equipment, sex products, adult products, sex toys and other products.
Keywords:
2 poles vibration motor, N20 vibration motor, 3v vibration motor
Payment:
1.Payment methods : Paypal, T/T
Shipping:
1.Delivery: DHL/FedEx 3-5 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.
FAQ
Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It’s better to offer application prototype drawings to us if possible.
Q: What’s your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.
Q: What’s the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.
