8mm Coin Vibration Motor – 2mm Type Model NFP-WS0825

$5.00

(6 customer reviews)

8mm Vibraton Motor Small Volume Price (USD)

QTY BREAK UNIT PRICE
1+ $5.00
100+ $3.00
1,000+ $2.84

Contact us for a quotation for production quantities, customizations and integration.

DATA SHEET

8mm Long Lifetime Brushless Coin Vibration Motor 2.5mm Type Model NFP-WS0825


2s on, 1s off, 1 cycle, 500,000 cycles Lifetime 3V DC Flat Coin Vibration Motor, Φ8mm Diameter, 2.5mm Thickness, Custom Wire Length, Jst, Molex, 3M adhesive.

Motor Model: NFP-WS0825
Rated Voltage: 3V DC
Motor Diameter: 8mm ± 0.05mm
Motor Thickness: 2.5mm ± 0.1mm
Rated Current: 80mA max
Rated Speed: 15,000 ± 3,000rpm
Start Voltage: 2.5V max
Noise: ≤ 50dB
Amplitude: 1.0G+
Wire length: 50mm



8mm Small Vibration Motor Brushless Type Outline Drawing


brushless-vibration-motor-NFP-WS0825



What’s Inside A Brushless Coin Vibration Motor?


A brushless coin vibration motor typically consists of a small, thin disc-shaped rotor that is mounted off-center within a circular stator. The rotor is composed of a permanent magnet and is surrounded by a coil of wire that is fixed to the stator. When an electrical current is applied to the coil, it creates a magnetic field that interacts with the magnet on the rotor, causing it to spin rapidly.

The spinning rotor creates vibrations that are transferred to the surface it is mounted on, producing a buzzing or vibrating effect. Unlike traditional brush motors, brushless motors do not have carbon brushes that wear out over time, which makes them more reliable and efficient.

Inside Of A Brushless Dc Coin Vibration Motors

Tiny Brushless Vibration Motors Mass Production


8mm-brushless-vibration-motors

8mm Brushless Vibration Motor Applications


Long lifetime 8mm small vibration motors used for bracelets wrist for haptic feedback. Vibration alerting function. Mainly used in high-end mobile phones, and personal digital devices, etc.

small-coin-type-vibration-motors-used-for-bracelets

All the small coin type vibration motors are 100% tested before shipping as follow, to learn more you can click the play button below:

how-we-test-the-brushless-coin-type-vibration-motor

Keywords:
vibration motor, vibration motors, enclosed vibration, encapsulated vibration, vibrating motor, eccentric mass, enclosed vibrating motor, enclosed vibration motors, small vibration motor, mini vibration motor, brushless vibration motor

Payment:
1.Payment methods : Paypal, T/T

Shipping:
1.Delivery: DHL/FedEx 3-5 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.

FAQ
Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It’s better to offer application prototype drawings to us if possible.

Q: What’s your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.

Q: What’s the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.

Free Shipping Site-wide When You Spend More Than $150

Click The Following Button To Copy the Coupon Code When You’re Going To The Checkout


Still can’t find ideal motors?

Get A Quote Within 8 Hours Contact Now! Any question about Micro DC Motor, Spec, Data-Sheet, Quote…

If you want a custom lead wire connection of the water resistant vibration motors. Such as alternate lead wire length & strip lengths, with a connector (e.g. Molex, JST). You can contact us from the footer form, tell us your need. Any problems will be taken seriously and will be answered professionally, so pls do not hesitate to contact us by the footer form.

6 reviews for 8mm Coin Vibration Motor - 2mm Type Model NFP-WS0825

  1. Katlyn

    I’ve used several small coin dc motors in the past, but this one stands out. It’s robust, energy-efficient, and offers continuous and steady vibration. Whether it’s for prototyping or hobby projects, I think this motor is a reliable choice!🌟

  2. Brian Waldman

    Great 8mm coin vibration motor for our projects. Vibrates pretty strongly with 3v. The motor works as expected, however, the exposed copper of the wire is short which causes it not easy to be soldered, and then I learnt the wire stripping length can be customized and I did it so.

  3. Darmon bernard

    Thank these long lifetime brushless motors. It was a last minute decision that i need something little slow. I mean i had one which has 20000 rpm but too fast for my science project. So, this one was the perfect fit for my project it worked so well.

  4. Michael Caruso

    The mini coin vibration motor performed well applied to our sports smart bracelet, have strong vibrating sense when running, fast delivery.😎

  5. Tobias Jørgensen

    Excellent small vibrating motor, can feel its vibration and receive forceful haptic feedback. It was very well packaged by the seller, it is important to me and I’m satisfied with it.

  6. Lev Ilyayev

    We used 8mm long lifetime coin type vibration motor to make tooth brush bots and they worked great! The flat shape coin vibration motor can continue working over 250hours!
