8mm Coin Vibration Motor 3.4mm Type Model NFP-C0834

5.00$

1 Star2 Stars3 Stars4 Stars5 Stars (9 votes, average: 4.89 out of 5)
Loading...

Small Volume Pricing (USD $)

QTY BREAKUNIT PRICE
1+$5.00
10+$3.00
50+$2.50
100+$0.99
500+$0.85

Contact us for a quotation for production quantities, customizations and integration such as custom wire length or with JST/ Molex connectors.

597 in stock

8mm Coin Vibration Motor 3.4mm Type Model NFP-C0834

Coin vibration motors, also known as shaftless or pancake vibrator motors, generally in Ø7mm – Ø12mm diameters. Within the coin motor range, we offer both leaded and spring & pad mountable versions. Due to their small size and enclosed vibration mechanism, coin vibrating motors are a popular choice for many different applications.

Contact us for a quotation for production quantities, customizations and integration.

3v dc coin motor for Health protection equipment /Personal care 0834, Best Quality for 3.0V DC Coin Type Vibrating Motors are widely used for cell phone ,Adult Products, Sex Toys, Sex product , Dental equipment,Electric Toothbrush, Fire security systems, Beauty product, Mobile Phone, Cell Phone, Pager, Personal care,Health product equipment ,Massager, Massage Rod, Eye Massager, Body Massager, Vibrator. etc

A coin vibration motor may be used in applications such as smart watches, fitness trackers and other wearable devices. They are commonly used to provide the user with discrete alerts, alarms or haptic feedback. We can supply our vibration motor with a variety of connectors, spring contacts, FPC or with bare contact pads. We can also design a custom FPC for your application. If your application requires it, foam pads of varying thicknesses and/or double stick tape tape may also be added.

NFP-C0834



Model: NFP – C0834
DC mini vibration motor, ERM Motor
Termination Style: Free wire
Lead free / RoHS Compliant
Operating Temperature: -20°C ~ 70°C
Lead time 2~3 days to world wide
Shipment: DHL Door to Door
Payment: PayPal

Body Diameter: 8.0mm
Body Thickness: 3.4mm
Rated Voltage: 3.0V
Operating voltage: 2.7~3.3V
Max current: 100mA
Typical Rated Operating Current: 69mA
Rated Vibration Speed: 12,000rpm
Vibe Force: 0.7G

Keywords:
Micro dc motors, small dc motors, dcmotors, motor dc, micro dc motor, 3v dc motor, pager motor, cylindrical vibration motors, spur gear motor, mini metal gear motor

Payment:
1.Payment methods : Paypal, T/T

Shipping:
1.Delivery: DHL door to door 3-4days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.
5.In order to ensure you receive your order tax free upon import, we will declare it with a lower value, pls be noted ,thanks!

FAQ

Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It's better to offer application prototype drawings to us if possible.

Q: What's your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.

Q: What's the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.

Still Can't Find Ideal Motors?


The electrical parameters of the motor can be adjusted. For example, the two main factors determining the vibration force: the size of the pager motor eccentric mass and the speed requirement. , voltage, current can be adjusted according to customer needs. Some encapsulated vibration motors adding terminals connectors, which are our customized products according to different customers. You can also contact us in the bottom contact form to ask for your needs.

If you want a custom lead wire connection of the water resistant vibration motors. Such as alternate lead wire length & strip lengths, with a connector (e.g. Molex, JST). You can contact us from the footer form, tell us your need. Any problems will be taken seriously and will be answered professionally, so pls do not hesitate to contact us by the footer form.
