8mm Coreless DC Motor – 23mm Type Model NFP-D8623
$8.00
Experience high efficiency with the 8mm Coreless DC Motor, perfect for agile micro quadcopters and RC drones. Elevate your flight today!
Notice: this motor model need to make new ones that would take extra 2-3 weeks.
| Quantity | Price | Discount |
|---|---|---|
| 20 - 99 | $8.00 | 0% |
| 100 - 999 | $2.85 | 64.38% |
| 1000+ | $2.05 | 74.38% |
Micro Brushed DC Motor Parameters
The NFP-D8623 series is an 8.6mm micro brushed DC motor line for compact and high-power products. It uses a precious metal brush and commutator for small drive systems.
First, this 8mm miniature DC motor is suitable for RC drones, micro quadcopters, and DIY projects. Also, it offers 3.4V and 7.4V options for different speed and power needs.
In addition, each motor has a compact 8.6mm x 23mm body. As a result, it can fit small products that need light weight, high speed, and strong torque.
Main Product Features
- First, optimized for flight: The motor can support responsive drone flight and small propeller drive systems.
- In addition, compact design: The 8.6mm x 23mm body fits micro quadcopters and RC drones.
- Also, high output power: The 7.4V version reaches up to 16.49W max output power.
- Next, easy installation: The motor can be used in DIY projects with simple wiring.
- Finally, custom support: Wire length, connector, and eccentric rotating mass options can be discussed.
8.6mm Micro Brushed DC Motor Performance Data
Next, the table below helps users compare voltage, speed, current, torque, power, efficiency, size, and weight. Therefore, it is easier to choose the right NFP-D8623 model for a small drone or compact device.
| Motor Model | NFP-D8623-1-3.4 | NFP-D8623-2-7.4 |
|---|---|---|
| Voltage | 3.4V | 7.4V |
| Terminal resistance | 0.4Ω | 0.8Ω |
| No-load-speed | 33,500rpm ± 10% | 47,000rpm ± 10% |
| No-load-current | 127mA | 150mA |
| Stall torque | 82.2g.cm | 136.75g.cm |
| Stall current | 9,090mA | 9,460mA |
| Max output power | 7.065W | 16.49W |
| Max efficiency | 73% | 74% |
| Torque constant | 9.2g.cm/A | 14.7g.cm/A |
| Rotor inertia | <0.15g.cm² | <0.15g.cm² |
| Weight | 6.1g | 6.1g |
| Rotation | CW | CW |
| Resistance | 100V, > 5MΩ | 100V, > 5MΩ |
| Motor Length | 23.0 ± 0.2mm | 23.0 ± 0.2mm |
| Motor Diameter | 8.60 ± 0.1mm | 8.60 ± 0.1mm |
| Output Shaft Diameter | 1.2mm | 1.2mm |
Also, the NFP-D8623-2-7.4 gives higher speed, higher torque, higher max output power, and higher efficiency. However, the NFP-D8623-1-3.4 is useful when the system needs a lower voltage motor.
Therefore, users can choose the 7.4V model for stronger power, or choose the 3.4V model for lower-voltage drone and toy projects.
Where To Buy Small DC Motors Outline Drawing
First, custom design service is available for this motor. For example, users can discuss connector options, wire length, and an eccentric rotating mass.
In addition, this 8.6mm coreless motor kit can support drone building and small RC projects. As a result, it is useful for DIY users and drone developers.
Outline Drawing and Product Fit
- First, small body: The 8.6mm x 23mm size helps save space.
- In addition, light weight: The 6.1g body helps reduce total drone weight.
- Also, strong output: The motor can provide high speed and strong torque.
- Next, drone use: It can support micro quadcopters and RC drones.
- Finally, custom options: Connector, wire length, and vibration mass options can be discussed.
Next, the product image below helps users review the motor shape and size. Also, it gives a clear view for sample selection and project matching.
Drone and DIY Project Benefits
First, the compact size makes these motors useful for small quadcopters and RC drones. Therefore, they can help reduce weight and improve flight response.
In addition, the motors provide strong power for their size. As a result, they can handle the drive needs of many micro flight systems.
Also, installation is simple for many DIY projects. Therefore, hobbyists and developers can add the motor to new drone builds more easily.
Typical Applications
- Micro quadcopters
- RC drones
- DIY hobby projects
- Electric toys
- Small vibration devices
- Compact high-speed drive systems
Finally, the NFP-D8623 micro brushed DC motor is a good fit for small products that need high speed, strong torque, compact size, and easy project integration.
