9mm Coin Vibration Motor – 3mm Type Model NFP-WS0934

$5.00

(5 customer reviews)

9mm Brushless Vibraton Motor Small Volume Price (USD)

QTY BREAK UNIT PRICE
1+ $5.00
100+ $3.35
1,000+ $2.99

Contact us for a quotation for production quantities, customizations and integration.

9mm Brushless Coin Vibration Motor 3.4mm Type Model NFP-WS0934


This type brushless motor is a coin shape motor, the internal IC driving the rotation. The advantage showcases its long lifecycle – 1 million cycles lifetime.

Motor Model: NFP-WS0934
Rated Voltage: 3V DC
Motor Diameter: 9mm ± 0.05mm
Motor Thickness: 3.4mm ± 0.1mm
Rated Current: 80mA max
Rated Speed: 9,000 ± 14,000rpm
Start Voltage: 2.5V max
Noise: ≤ 50dB
Amplitude: 1.4G+



Long Lifetime Nano Vibration Motor Outline Drawing


9mm-diameter-3v-long-lifetime-brushless-vibration-motors

9mm Long Lifetime Brushless Vibration Motors Applications


tiny-vibration-motors-inside-bond-touch-application-pair-of-bracelets

Pancake Tiny Coin Vibration Motors Mass Production


Long Lifetime Flat Coin Vibration Motor, BLDC Brushless DC Motor, Φ9mm Diameter, 3.4mm Thickness, Custom Design Wire Length, Jst, Molex Terminals Options. 3V DC vibration motors used for scanners and detectors, safety equipment, electronic tools, pagers, meters, GPS…

brushless-erm vibration motor

long-lifetime-brushless-tiny-vibration-motors

coin-type-vibration-motor

Application:
Mainly used in high-end mobile phones, and personal digital devices, etc.

Keywords:
BLDC vibration motor, brushless dc motor, flat coin vibration motor, long lifetim motor, coin motor, pancake motor

Payment:
1.Payment methods : Paypal, T/T

Shipping:
1.Delivery: DHL/FedEx 3-5 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.

FAQ
Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It’s better to offer application prototype drawings to us if possible.

Q: What’s your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.

Q: What’s the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.

Still can’t find ideal motors?


The electrical parameters of the motor can be adjusted. For example, the two main factors determining the vibration force: the size of the pager motor eccentric mass and the speed requirement. , voltage, current can be adjusted according to customer needs. Some encapsulated vibration motors adding terminals connectors, which are our customized products according to different customers. You can also contact us in the bottom contact form to ask for your needs.

If you want a custom lead wire connection of the water resistant vibration motors. Such as alternate lead wire length & strip lengths, with a connector (e.g. Molex, JST). You can contact us from the footer form, tell us your need. Any problems will be taken seriously and will be answered professionally, so pls do not hesitate to contact us by the footer form.
