10mm Coin Vibration Motor – 2mm Type Model NFP-C1020

$3.00

(8 customer reviews)

Boost your designs with a flat coin vibration motor that provides strong vibrations in a tiny package. Perfect for innovative applications. Shop today!

Contact us for a quotation for production quantities, customizations and integration.

DATASHEET

USDUSD
EUREUR
GBPGBP
JPYJPY
AUDAUD
CADCAD
NZDNZD
HKDHKD
SGDSGD
QuantityPriceDiscount
1 - 99$3.000%
100 - 499$1.2060%
500 - 999$0.9967%
1000+$0.8571.67%

10mm Flat Coin Vibration Motor 2mm Type Model NFP-C1020


First, this tiny, button-type, shaftless vibration motor provides strong haptic feedback. In addition, it shakes with a vibration amplitude of 0.8g and needs no external moving parts. The unit has a 10mm diameter and 2mm height.

Model Value
Motor Model: NFP-FLAT-C1020L
Motor Diameter: 10mm ± 0.1mm
Motor Thickness: 2mm ± 0.1mm
Rated Voltage: 3.0V DC
Rated Speed: 11,000 ± 2,500rpm
Rated Current: 80mA max
Nominal Amplitude Vibe Force: 1.1G



Coin Vibration Motor Outline Drawing


We can customize wire length based on your needs. For example, we usually ship standard 50mm or 100mm lead wires directly.

1020 eccentric rotating mass vibration motor drawing

Small Vibration Motor Uses in IEEE Projects


Researchers used these motors in a haptic study. First, participants wore two vibrotactile bands on their arms near elbow and shoulder joints. Next, each band mounted two eccentric rotating mass (ERM) motors on inner and outer arm parts. Therefore, the system created distinct touch cues.

The selected motor is a 10mm coin type running on 3V DC and 61mA current. As a result, it achieves a nominal speed of 14,000 ± 3,000rpm. The graphic below illustrates the layout clearly:

IEEE Localization Performance Cues on Both Arms

“Localization Performance of Multiple Vibrotactile Cues on Both Arms”

Key Features & Options

  • Compact coin design ideal for wearable tech and small devices.
  • Easy mounting with sticky backing options.
  • Custom lead wire lengths available for different setups.

Keywords: coin vibration motor price, average haptic motor, coin vibration motor datasheet, erm motor, coin vibration motor, button vibration motor

Payment:
1.Payment methods : Credit Card, Paypal, T/T, Google Pay, Apple Pay...
Shipping:
1.Delivery: DHL/FedEx 3-5 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.
FAQ
Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It's better to offer application prototype drawings to us if possible.
Q: What's your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.
Q: What's the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.

Free Shipping Site-wide When You Spend More Than $150

8 reviews for 10mm Coin Vibration Motor - 2mm Type Model NFP-C1020

  1. Wang Mei –

    I like the size of this 10mm motor; it’s perfect for subtle notifications. Plus, it’s compact and reliable for small projects that only need subtle vibrations.

  2. Jarrod Elem –

    This motor is superior to the 8mm version. t’s got a nice, strong vibration that’s great for applications like alarms and notifications. 🔔📢

  3. Guillermo McInnes –

    I used these for various projects and haven’t had any issues with them yet. The wires are thin, so be careful when stripping them, and the adhesive pads on the back are handy, which is a plus for me. 🧐

  4. Sean Devanney –

    Cool and pretty powerful once you glue them (peel protector to reveal sticky surface) to something. The coin vibration motors were able to run directly from button battery for a test but I am running them through a driver chip for the finished product, and it did vibrated.

  5. Karolayne Martins –

    Thank you. I ordered the 50 flat coin vibration motor because it looked like it would fit well into my project. When the motors arrived I was able to use them normally, it worked so well.

  6. Gerald Heinrichs –

    This coin vibrating motor’s function meets our requirement well, the motor is powerful when running though it is so small.

  7. Andrea Musso –

    The Coin Vibration Motor functions well.

  8. Jeremy Kress –

    Good mini coin vibration motor.
    First time purchasing this particular motor. It seems to work fine.
