7mm Encapsulated Vibration Motor – 24mm Type Model NFP-7C-FS0725
$3.00
Enclosed & Encapsulated Vibration Motor Small Volume Price (USD)
| QTY BREAK | UNIT PRICE |
|---|---|
| 1+ | $3.00 |
| 100+ | $1.99 |
| 1,000+ | $1.20 |
Contact us for a quotation for production quantities, customizations and integration.
3.7V DC Encapsulated Small Vibration Motor Model NFP-7C-FS0725-306-108 Parameters
7 mm diameter, 25 mm length vibrating motor. Mini Coreless Motor Waterproof Vibration Motor for Toy DIY Our line of enclosed vibration motors are either available with either a plastic capsule made of polystyrene or a metal capsule made of nickel plated steel. Vibration motors that make use our metal capsule design are fully encapsulated and may be over molded.
They incorporate a plastic cap at the end of the capsule that is epoxied in place to prevent intrusion of liquids and are water proof. The wires that pass through this cap are epoxied as well. Encapsulated vibrating motors are best suited for applications that require the electronics assembly to be potted, over molded or fully submerged in a liquid. It may also be suitable for applications that require a vibration motor that is intrinsically safe.
| Motor Model: | NFP-7C-FS0725 |
|---|---|
| Capsule Diameter: | Φ7mm ± 0.02mm |
| Motor Length: | 24.5mm ± 0.1mm |
| Motor Diameter: | Φ6mm ± 0.03mm |
| Motor Length: | 17mm ± 0.3mm |
| Rotation: | CW/CCW |
| Waterproof Level: | IP67 |
| Ecc. Weight Radius: | 2.5mm |
| Ecc. Weight Length: | 4.0mm |
| Voltage: | 3V DC |
| Load speed: | 12,000rpm |
7mm Diameter Waterproof Vibration Motor Datasheet Outline Drawing
7 mm diameter, 24 mm length vibrating motor is made of metal capsule (nickel plated steel). Vibration motors that make use our metal capsule design are fully encapsulated and may be over molded. They incorporate a plastic cap at the end of the capsule that is epoxied in place to prevent intrusion of liquids and are water proof.
Enclosed Vibration Motors Applications
Small vibration motor, waterproof type using in Artificial Limbs, and many other applications, learn more…
The wires that pass through this cap are epoxied as well. Encapsulated vibrating motors are best suited for applications that require the electronics assembly to be potted, over molded or fully submerged in a liquid. It may also be suitable for applications that require a vibration motor that is intrinsically safe. As of this time, we do not have an IS or IP rating for any of our parts. Models that make use of our plastic capsules may be used in less demanding applications and in most cases may be potted.
As of this time, we do not have an IS or IP rating for any of our parts. Models that make use of our plastic capsules may be used in less demanding applications and in most cases may be potted.1670-1020-ND, Z6DL2B0055211, VIBRATION MOTOR CYL 3V WIRE, DC Motor Vibration, ERM 11000 RPM 3VDC, Cylindrical Vibrator Motors.Connectors and rubber sleeves / boots may be added to most leaded parts.
Encapsulated vibration motors are designed to be over moulded working in low temperature/pressure conditions to be watertight, or seal them for use in harsh. Fast delivery to all over the world. DHL door to door. No MOQ, No Agent, Factory Direct.
Keywords:
enclosed vibration motors, encapsulated vibration motors, external moving parts, enclosed vibrating motors, erm vibration motors, enclosed vibration motor, eccentric rotating mass, 1670-1020-ND, Z6DL2B0055211, vibration motor, dc motor vibration, cylindrical vibrator motors, Model 306 108
Payment:
1.Payment methods : Paypal, T/T
Shipping:
1.Delivery: DHL/FedEx 3-5 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.
FAQ
Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It’s better to offer application prototype drawings to us if possible.
Q: What’s your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.
Q: What’s the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.
Still can’t find ideal motors?
The electrical parameters of the motor can be adjusted. For example, the two main factors determining the vibration force: the size of the pager motor eccentric mass and the speed requirement. , voltage, current can be adjusted according to customer needs. Some encapsulated vibration motors adding terminals connectors, which are our customized products according to different customers. You can also contact us in the bottom contact form to ask for your needs.
If you want a custom lead wire connection of the water resistant vibration motors. Such as alternate lead wire length & strip lengths, with a connector (e.g. Molex, JST). You can contact us from the footer form, tell us your need. Any problems will be taken seriously and will be answered professionally, so pls do not hesitate to contact us by the footer form.
