7mm Encapsulated Vibration Motor – 24mm Type Model NFP-E0716M
$5.00
Get the best in vibration alerting with our encapsulated vibration motor waterproof. Small size, strong sealing, and long-lasting performance await!
| Quantity | Price | Discount |
|---|---|---|
| 1 - 9 | $5.00 | 0% |
| 10 - 49 | $3.00 | 40% |
| 50 - 99 | $2.50 | 50% |
| 100 - 999 | $1.99 | 60.20% |
| 1000+ | $1.49 | 70.20% |
NFP-E0716M Enclosed Vibration Motor Metal Case
This metal capsule encapsulated vibration motor can be used for vibration alerting.
High efficiency | Low energy consumption | Low noise | Small size | Strong sealing | Fast response | Low starting current | Long lifetime
| Motor Model: | NFP-E0716M |
|---|---|
| Rated Voltage: | 3V DC/ 3.7V DC |
| Start Voltage: | 1.0V max |
| Rated Current: | 300mA max |
| Stall Current: | 850mA max |
| Body Diameter: | 7.5mm |
| Body Length: | 24mm ± 0.3mm |
| Motor Diameter: | 7mm |
| Motor Length: | 16.6mm |
| Ecc. Weight Radius: | 2.7mm ± 0.1mm |
| Ecc. Weight Length: | 5.0mm |
| Rated Speed: | 14,500RPM or 16,500rpm |
| Shaft End Play: | 0.05mm – 0.3mm |
| Wire Gauge: | 30AWG UL1571 |
| Terminal Resistance: | 5.6Ω ± 25% |
| Wire Length: | 100mm |
| Nominal Amplitude Vibe Force: | 5.10G |
Overmoldable Vibration Motors Ouline Drawing
Small powerful motors NFP-E0716M is used in Mi Electric Toothbrush. Vibration makes toothbrushes more efficient to use. Also can be used in other applications. Contact us for a quotation for production quantities, customizations and integration.
Encapsulated Vibration Mass Production
7mm Vibration Motors Applications
Operating Temperature of a Standard Coreless Vibration Motor
The operating temperature of a coreless motor (ironless motor) depends on several factors, including the type of internal magnetic material, winding material, load conditions, and operating environment.
General Operating Temperature Range:
– Recommended Operating Temperature: -10°C to 60°C
– Maximum Operating Temperature: -20°C to 80°C (performance may be affected)
Impact of Temperature on Magnets:
Most coreless motors use neodymium (NdFeB) magnets, whose magnetic properties weaken as temperature increases, affecting motor efficiency and output performance:
– Below 60°C: Minimal impact, magnetic properties remain stable.
– Above 80°C: Magnetic strength starts to weaken, reducing motor torque.
– Above 150°C: Standard neodymium magnets may suffer irreversible demagnetization, leading to performance degradation or motor failure.
How to Prevent High-Temperature Issues:
1. Reduce Continuous Load – Avoid running the motor at full load for long periods to prevent overheating.
2. Optimize Heat Dissipation – Ensure proper ventilation or use heat sinks to maintain a stable operating temperature.
3. Use High-Temperature Magnets – For applications requiring higher temperatures, consider Samarium Cobalt (SmCo) magnets, which can withstand up to 250°C.
4. Adjust Driving Voltage – Avoid excessive voltage, which can overheat the windings and shorten motor lifespan.
If your application requires extended operation in high-temperature environments, it is recommended to consider above points to ensure stability and longevity.
Keywords:
encapsulated vibration motor, encapsulated motor, waterproof vibration motor, vibrator motor, 1670-1023-ND, Z7AL2B1692082
1.Payment methods : Paypal, T/T
Shipping:
1.Delivery: DHL/FedEx 3-5 days.
2.Item will be shipped within 1-3 business days after the payment.
3.If you haven’t received the item on the Delivery Time, pls contact us by email if you have any questions. Normally, we will give you a reply within 24 hours, if not, pls check the spam of your email box. We will do our best to help you solve the problems.
4.Please make sure your address is matched with the finally shipping address before you pay.
FAQ
Q: If customized, what information should you provide?
A: You need to provide the basic specification of the motor, such as: Dimensions, Sizes Applications, Voltage, Speed and Torque. It’s better to offer application prototype drawings to us if possible.
Q: What’s your main motors?
A: Diameter 4mm~42mm Dc Micro Motor And Gear Motor, Auto Dc Motor, Electric Motor, Gear Motor, Mini Dc Motor, Brush Dc Motor, Brushless Dc Motor, Spur Gear Motor, Micro Motor, Vibration Motor Etc.
Q: What’s the main application of the micro dc motor?
A: Our mini DC motors are widely used in Home Applications, Office Equipment, Health-Care Application, Sanitation Industry, High-Class Toy, Banking System, Electronic and Electrical Tools, Automation Industry, Bank Equipments, Payment Equipments, Vending Machines, Power Door Lock, Electric Door Lock.
