11mm Encapsulated Vibration Motor – 26mm Type Model NFP-E1015

$6.50

(8 customer reviews)

Small Volume Pricing (USD $)

QTY BREAK UNIT PRICE
1+ $6.50
10+ $6.00
50+ $5.50
100+ $5.00
500+ $2.50

Contact us  for a quotation for production quantities, custom wire length or with JST/ Molex connectors.

DATA SHEET

CAD DRAWING

Encapsulated Vibration Motor Motors Performance


This waterproof dc motor’s other part number: 304-116, 307-103, 307-103.002, 307-103.004, 307-103.005, 307-103.007, 307-105.003.  You can order development samples from this product page, and for engineering & manufacturing you can contact one of our Sales Engineers for a quotation for production and consultation for customization and integration services by the below form.

If you want to feel the vibration amplitude of this vibratory motor, you can watch the following video: Why Is Vibration Amplitude In G?

Motor model: NFP-E1015
Wire length: 100mm
Rated voltage: 3.7 V DC
Rated current: 450mA max
Rated Speed: 9,500±2,000 rpm
Shaft end play: 0.05-0.30mm
Unmarked tolerance: ±0.1mm
Typical Norm. Amplitude: 10G



Big Amplitude Vibration Motor Outline Drawing


3.7v vibration motor NFP-E1015 inside a blue plastic capsule which make it waterproof. Prevent liquid from entering. Small size with powerful vibration force “10G”.

waterproof-vibration-motor-outline-drawing



Eccentric Rotating Mass Vibration Motor Performance Curve


small-electric-vibrating-motors

Powerful Vibration Motor Factory Mass Production


waterproof-vibration-motors



Enclosed Vibration Motors Applications


This vibration alert technology can be used to add tactile feedback to light handheld devices, making them easier to use. This can be especially helpful for devices that are used in difficult or dangerous situations, like medical instruments or electric torque wrenches.

enclosed-vibration-motor-using-in-Joystick
